The Muncie 40TF8500 is a PTO gear adapter designed to mount between the vehicle transmission and the power take-off unit. It carries the F85 gear designation with 39 teeth. Published dimensional data from Muncie's own service-parts document SP93_03_Adpter_Gear_Assemblies.pdf lists the following measurements for this part: A = 3.383 in. (85.9 mm), B = 0.1617 in. (15.7 mm), C = 1.102 in. (28.0 mm), and D = 5.046 in. (128.2 mm). Associated service components referenced alongside 40TF8500 include part numbers 05T35368, 41T35367 (quantity 2), and 10T35369. Muncie gear adapters are used to increase clearance, reposition the PTO output shaft, or match PTO shaft rotation to driven equipment requirements. Call us to confirm proper fit for your application.
Features
F85 gear designation with 39 teeth
Dimension A: 3.383 in. (85.9 mm)
Dimension B: 0.1617 in. (15.7 mm)
Dimension C: 1.102 in. (28.0 mm)
Dimension D: 5.046 in. (128.2 mm)
Associated service parts: 05T35368, 41T35367 (qty 2), 10T35369
Tech Specs
- Gear Designation: F85
- Teeth: 39
- Dimension A: 3.383 in. (85.9 mm)
- Dimension B: 0.1617 in. (15.7 mm)
- Dimension C: 1.102 in. (28.0 mm)
- Dimension D: 5.046 in. (128.2 mm)
- Associated Service Parts: 05T35368, 41T35367 (qty 2), 10T35369
- Source Document: SP93_03_Adpter_Gear_Assemblies.pdf
