The Muncie 03T41320 is a CS6-series power take-off input idler shaft gear identified by Muncie as part A6705. It carries a 26/18 tooth count, 6.86 diametral pitch, and a 20-degree pressure angle spur gear profile. This gear is a service part for the Muncie CS6 PTO, a direct-mount unit that commonly pairs with Allison 1000/2000-series transmissions as well as many manual transmissions. The CS6 series accommodates six transmission input gear configurations, so confirming the correct ratio and tooth count for your installation is essential before ordering. Call Pro Gear and Transmission to confirm proper fit for your application.
Features
Muncie part number 03T41320, manufacturer ID A6705
26/18 tooth count, 6.86 diametral pitch spur gear
20-degree pressure angle gear profile
Service replacement gear for the Muncie CS6-series power take-off
CS6 PTO is compatible with Allison 1000/2000-series and many manual transmissions
Call Pro Gear and Transmission to verify fitment before ordering
Tech Specs
- Part Number: 03T41320
- Manufacturer ID: A6705
- Gear Type: Spur
- Tooth Count: 26/18
- Diametral Pitch: 6.86P
- Pressure Angle: 20 degrees
- Application: Muncie CS6-series power take-off input
