Muncie CB6 Series Parts List & Service Manual

View the official Muncie PTO CB6 parts manual (PDF)Download PDF

Model Number Construction

Item	Part No.	Description	Qty	Notes	Price

Detail A Output Shaft Assemblies

Click a number on the diagram to highlight that part below.

Item	Part No.	Description	Qty	Price
1	21T36511	Washer	1	$71.82	Add to Cart
2	21T36512	Plate	1	$50.58	Add to Cart
3	24T27240	Snap Ring	1	$8.86	Add to Cart
4	24T35480	Snap Ring	2	$6.51	Add to Cart
5	21T29017	Thrust Washer Bell Gear	2	$30.01	Add to Cart
7	10T36285	Needle Roller Bearing	1	$60.48	Add to Cart
7A	10T37008	Needle Roller Bearing E Output Shaft	1	$47.38	Add to Cart
9	02T38792	Clutch Hub	1	$148.59	Add to Cart
	21T38907	Washer	1	$73.80	Add to Cart
	24T37951	Snap Ring	1	$5.94	Add to Cart
	49T38818	Flange	1	$136.12	Add to Cart
	49T38819	Clutch Hub	1	$611.87	Add to Cart
10	49T33564	Friction Disc (cs)	8	$15.34	Add to Cart
	49T33564	Friction Disc (cb)	3	$15.34	Add to Cart
11	49T33563	Spacer Disc (cs)	7	$12.04	Add to Cart
	49T33563	Spacer Disc (cb)	4	$12.04	Add to Cart
12	27T36112	Spring	1	$12.84	Add to Cart
13	49T36560	Piston (CS8)	1	$139.36	Add to Cart
	49T38878	Piston (CS6)	1	$220.96	Add to Cart
	49T42027	Piston (i D, E, Z) ,	1	$164.56	Add to Cart
	49T38758	Piston (2 & 4 Arr.)	1	$187.18	Add to Cart
14	12T36054	O-ring (CS8)	1	$14.04	Add to Cart
	12T36472	O-ring (CS6)	1	$12.75	Add to Cart
15	49T36561	Piston Cup (5 .25 " O.d.) (CS8)	1	$145.15	Add to Cart
	49T36464	Piston Cup (4.50 " O.d.) (CS6)	1	$158.64	Add to Cart
	49T36115	Piston Cup (5 .25 " O.d.) (i D, E, Z) ,	1	$161.54	Add to Cart
	49T38757	Piston Cup (5 .25 " O.d.) (2 & 4 Arr.)	1	$190.64	Add to Cart
16	24T36470	Snap Ring Std Output .	1	$2.28	Add to Cart
	24T36040	Snap Ring (i D, E, Z Output) ,	1	$6.09	Add to Cart
17	12T36471	O-ring Std Output .	2	$3.30	Add to Cart
	12T36053	O-ring (i D, E, Z Output) ,	2	$4.61	Add to Cart
18	25T35520	Cap Plug (“r”)	1	$2.00	Add to Cart
	25T35724	Cap Plug (“g” “k” “q” “s” & “6”) , , , ,	1	$2.31	Add to Cart
	25T35725	Cap Plug (“p”)	1	$2.28	Add to Cart
	25T37767	Cap Plug (“i ” & “d”)	1	$2.77	Add to Cart
	25T35936	Cap Plug (“z”)	1	$2.28	Add to Cart
	25T37387	Cap Plug (“t”)	1	$2.22	Add to Cart
19	24T24315	Snap Ring	1	—	Call for availability
20	28T39964	Brake Hub	1	$77.53	Add to Cart
21	12T35343	O-ring	2	$5.69	Add to Cart
22	12T39967	O-ring	1	$4.61	Add to Cart
23	28T39963	Piston	1	$210.49	Add to Cart
24	27T40389	Spring	1	$55.44	Add to Cart
25	28T40390	Spacer	1	$60.62	Add to Cart
26	24T35480	Snap Ring	1	$6.51	Add to Cart

Detail B End Cover Assemblies

Item	Part No.	Description	Qty	Price
27	19T36174	Setscrew	4	$5.11	Add to Cart
	19T41969	Setscrew (drop-in)	4	$3.41	Add to Cart
28	27T36173	Spring	4	$4.40	Add to Cart
29	25T21684	Pipe Plug	2	$2.31	Add to Cart
30	19T35237	Capscrew	4	$5.22	Add to Cart
31	15T36717	St. Closed Cover	1	$300.63	Add to Cart
	15T36860	Closed Cover (CS6G)	1	$303.92	Add to Cart
	15T39966	Closed Cover (cb*)	1	$99.07	Add to Cart
	15T41597	Closed Cover (w/ Drop-in Solenoid)	1	$202.28	Add to Cart
32	11T36124	Seal	1	$56.14	Add to Cart
33	24T36894	Snap Ring	1	$3.44	Add to Cart
34	12T34003	O-ring	1	$20.22	Add to Cart
35	10T21017	Bearing	1	$74.28	Add to Cart
	10T38248	Bearing	1	$75.04	Add to Cart
36	26T36175	Roll Pin	4	$4.24	Add to Cart
37	21T36473	Plate	1	$94.24	Add to Cart
38	35T40860	Solenoid	1	$376.57	Add to Cart
39	19T40859	Capscrew	2	$2.98	Add to Cart
40	28T39965	Brake Ring	1	$138.14	Add to Cart

Detail C Input Gear Assemblies

Item	Part No.	Description	Qty	Price
41	21T34621	Thrust Race	4	$16.91	Add to Cart
42	10T34620	Thrust Bearing	2	$46.25	Add to Cart
43	10T34006	Needle Roller Bearing	2	$36.00	Add to Cart
44	18T34622	Spacer	1	$22.88	Add to Cart
45	07T35947	Idler Shaft (03/04 Ratio, A6705)	1	$133.50	Add to Cart
	07T37071	Idler Shaft8 (05-14 Ratios)	1	$104.30	Add to Cart
	03T41318	26/14 6.86P 20° Pa Spur M6504		$949.60	Add to Cart
	03T41319	26/17 6.86P 20° Pa Spur M6505		$1,160.78	Add to Cart
	03T41320	26/18 6.86P 20° Pa Spur M6507		$1,160.78	Add to Cart
	03T42442	30/23 6.86P 20° Pa Spur M6509		$589.58	Add to Cart
	03T37067	20/30 6.1P 25° Pa 32.28° LH M6512		$1,065.80	Add to Cart
	03T37068	23/30 7P 25° Pa 30.78° LH M8307		$980.57	Add to Cart
	03T37984	42/30 10.1P 20° Pa Spur M8309		$980.57	Add to Cart
	03T37086	24/23 6.35P 20° Pa 22° LH S6007		$947.39	Add to Cart
	03T38356	24/26 6.35P 20° Pa 22° LH S6807		$947.39	Add to Cart
	03T38502	24/23 6.65P 20° Pa 21 .5° LH S6809		$947.39	Add to Cart
	03T38503	24/26 6.65P 20° Pa 21 .5° LH S6812		$871.63	Add to Cart
	03T38504	24/30 6.65P 20° Pa 21 .5° LH S7009		$947.39	Add to Cart
	03T38194	26/23 7P 23° Pa 26 LH S7107		$947.39	Add to Cart
	03T40234	26/26 7P 23° Pa 26 LH U6003		—	No longer available — call for replacement
	03T37741	28/18 8.38P 18° Pa 33.1 LH U6004		$493.12	Add to Cart
	03T37743	28/26 8.38P 18° Pa 33.1 LH U6005		$493.12	Add to Cart
	03T39447	28/23 8.38P 18° Pa 33.1 RH U6806		$800.90	Add to Cart
	03T43310	34/14 8.46P 20° Pa 29 LH U6807	I8403	$619.08	Add to Cart
	03T43311	34/17 8.46P 20° Pa 29 LH U6809	I8404	$744.98	Add to Cart
	03T43312	34/18 8.46P 20° Pa 29 LH U6809	I8405	$744.98	Add to Cart
	03T43313	34/23 8.46P 20° Pa 29 LH U6812	I8407	$744.98	Add to Cart
	03T37091	38/18 8.46P 20° Pa 29 LH U6814	I8505	$623.10	Add to Cart
	AND20TK6390	To Mount. Bearings And Requires A 03-04 Ratio	23M60350	—	Call for availability
47	10T35776	Tapered Roller Bearings	2	$54.96	Add to Cart
48	18T41452	Input Bearing Shim Input Bearing Shims Input Cone Spacer	1	$15.10	Add to Cart

Detail D PTO Housing Assemblies

Item	Part No.	Description	Qty	Price
50	43T37385	Orifice Fitting (p Special Feature) -	1	$15.23	Add to Cart
51	25T36570	Cap Plug	1	$2.00	Add to Cart
52	19T41118	Capscrew	1	$5.20	Add to Cart
53	16T41119	Cover	4	$28.62	Add to Cart
	12T35949	O-ring	2	$3.57	Add to Cart
	12T35774	O-ring Table C.1 Bearing –	2	$4.42	Add to Cart
55	26T37992	Dowel Pin (F84 Only)	2	$5.88	Add to Cart
56	19T35785	Set Screw Gasket	1	$3.61	Add to Cart
	23M60350X	Spacer	1	—	Call for availability

Detail D PTO Housing Assemblies (continued) Detail E Output Options

Item	Part No.	Description	Qty	Price
8	06T36892	Output Shaft “b” 1 .3 " Rd Keyed; CS6/8S – .	1	$362.49	Add to Cart
	06T37167	Output Shaft “b” 1 .3 " Rd Keyed; CS6/8G – .	1	$329.54	Add to Cart
	06T38767	Output Shaft “b” 1 .3 " Rd. Keyed; 2 & 4 Assy. –	1	$438.30	Add to Cart
	06T39874	Output Shaft “b” (CB6/8) –	1	$396.77	Add to Cart
16	24T36470	Snap Ring	1	$2.28	Add to Cart
35	10T21017	Bearing	1	$74.28	Add to Cart
58	26T01627	Woodruff Key	1	$5.78	Add to Cart
59	12T36751	O-ring	1	$8.14	Add to Cart
60	15TA5220	Flange/seal Assembly	1	$85.99	Add to Cart
61	19T41756	Capscrew	4	$1.94	Add to Cart
65	28T62371	Spacer, Bearing	1	$11.99	Add to Cart
8	06T37372	Output Shaft “2” “c” & “x” 1 .3 " -20T , ,	1	$531.76	Add to Cart
62	14T37357	Companion Flange “c”	1	$448.51	Add to Cart
	14T37378	Companion Flange “2”	1	$448.51	Add to Cart
63	21T20092	Flat Washer	1	$24.83	Add to Cart
64	19T38266	Capscrew	1	$3.57	Add to Cart
8	06T41013	Output Shaft “d” Din 5462 (euro)	1	$789.95	Add to Cart
	06T38996	Output Shaft “i ” Din 5462	1	$789.95	Add to Cart
	06T39526	Output Shaft “i ” Din 5462 (CS6/8G)	1	$763.11	Add to Cart
16	24T38347	Snap Ring	1	$5.57	Add to Cart
	28T39404	Spacer (“i ” CS6G Only)	1	$69.67	Add to Cart
18	25T35936	Cap Plug	1	$2.28	Add to Cart
35	10T38248	Bearing	1	$75.04	Add to Cart
59	12T38344	O-ring	1	$9.14	Add to Cart
60	14TA4824	Flange/seal (“i ”)	1	$628.06	Add to Cart
	14TA4817	Flange/seal (“d” & “i ” CS6G)	1	$781.00	Add to Cart
61	19T96512	Capscrew (“i ” Output)	4	$5.94	Add to Cart
	19M84478	Capscrew (“d” & “i ” CS6G)	4	$5.69	Add to Cart
8	06T40205	Output Shaft “e” 1 .25 " 14T	1	$531.76	Add to Cart
60	14TA5380	Flange/seal Assembly	1	$505.99	Add to Cart
61	19M84478	Capscrew	8	$5.69	Add to Cart

Detail E Output Options (continued)

Item	Part No.	Description	Qty	Price
8	06T36893	Output Shaft “k”	1	$531.76	Add to Cart
	06T37089	Output Shaft “p”	1	$531.76	Add to Cart
16	24T36470	Snap Ring	1	$2.28	Add to Cart
18	25T35724	Cap Plug “k”	1	$2.31	Add to Cart
	25T35725	Cap Plug “p”	1	$2.28	Add to Cart
35	10T21017	Bearing	1	$74.28	Add to Cart
59	12T36751	O-ring	1	$8.14	Add to Cart
60	14TA3996	Flange/seal Assembly	1	$278.76	Add to Cart
61	19T34462	Capscrew	4	$4.09	Add to Cart
65	28T62371	Spacer, Bearing Description “l” Output	1	$11.99	Add to Cart
8	06T37089	Output Shaft “l”	1	$531.76	Add to Cart
18	25T35725	Cap Plug	1	$2.28	Add to Cart
60	14TA5236	Flange/seal Assembly	1	$569.76	Add to Cart
8	06T38964	Output Shaft “r” “r” “q” & “t” Output	1	$516.32	Add to Cart
	06T37090	Output Shaft “q”	1	$637.53	Add to Cart
	06T37336	Output Shaft “t”	1	$531.76	Add to Cart
60	14TA3997	Flange/seal Assembly	1	$278.76	Add to Cart
61	19T39257	Capscrew	4	$3.30	Add to Cart
8	06T37090	Output Shaft “s”	1	$637.53	Add to Cart
18	25T37387	Cap Plug	1	$2.22	Add to Cart
60	14TA3999	Flange/seal Assembly	1	$278.76	Add to Cart
8	06T38908	Output Shaft “z”	1	$1,000.80	Add to Cart
16	24T38347	Snap Ring	1	$5.57	Add to Cart
18	25T35936	Cap Plug	1	$2.28	Add to Cart
35	10T38248	Bearing	1	$75.04	Add to Cart
59	12T38344	O-ring	1	$9.14	Add to Cart
60	14TA4818	Flange/seal Assembly	1	$290.28	Add to Cart
61	19T38249	Capscrew Description “6” & “7” Output	4	$4.09	Add to Cart
60	14TA4819	Flange/seal Assembly	1	$447.15	Add to Cart

Installation Kits 48TK4508 (12V “A” Option) & 48TK4509 (24V “K” Option)

Item	Part No.	Description	Qty	Price
1	44MB2164	Pipe Nipple	1	$5.22	Add to Cart
2	31M15759	Pressure Protection Valve	1	$120.08	Add to Cart
3	44MB6844	Fitting	1	$9.14	Add to Cart
4	45M44430	Tubing (30 Ft.)	1	$64.95	Add to Cart
5	44MB6942	Elbow Fitting	1	$10.62	Add to Cart
6	35M18653	Air Valve	1	$209.42	Add to Cart
7	44MB6842	Fitting	2	$6.66	Add to Cart
8	44MB2252	Street Tee	1	$8.29	Add to Cart
9	33T36299	Fuse Assembly	1	$11.93	Add to Cart
10	30T60228	Pressure Switch	1	$172.61	Add to Cart
11	34M18009	Ring Terminal	2	$2.82	Add to Cart
	34T36941	Wiring Pigtail	1	$38.67	Add to Cart
	PIN43	A Connection To The Allison “pto This Location (relay Not Supplied Suggested . .	TCM	—	Call for availability
12	34T36362	Closed End Crimp	1	$2.39	Add to Cart
13	37T42512	Wire (12 Ft.)	1	$7.07	Add to Cart
14	32M12001	Light Assembly 12V With The “p” Special Feature	1	$44.73	Add to Cart
15	43T37385	Orifice Fitting	1	$15.23	Add to Cart
16	45M4R536	Lube Hose Assembly	1	$62.22	Add to Cart
17	36MA1004	Dash Bracket	2	$49.06	Add to Cart
18	36T38978	Face Plate	1	$5.81	Add to Cart
19	36MK1007	Dash Bracket Bolt Kit	1	$5.27	Add to Cart
20	25T21684	Pipe Plug	1	$2.31	Add to Cart

Electric/Air Shift System

Item	Part No.	Description	Qty	Price
1	44MB2164	Pipe Nipple	1	$5.22	Add to Cart
2	31M15759	Pressure Protection Valve	1	$120.08	Add to Cart
3	44MB6844	Fitting	2	$9.14	Add to Cart
4	45M44430	Tubing (30 Ft.)	1	$64.95	Add to Cart
5	35M30692	Street Tee	1	$314.26	Add to Cart
6	35M30692	12V Solenoid Valve	1	$314.26	Add to Cart
7	44MB6842	Fitting	2	$6.66	Add to Cart
8	44MB2252	Street Tee	1	$8.29	Add to Cart
9	44MB0942	Reducer Bushing	1	$3.90	Add to Cart
10	31M14732	Press. Safety Switch (no 80 Psi)	1	$87.43	Add to Cart
11	37T42512	Wire (12 Ft.)	2	$7.07	Add to Cart
12	33T36299	Fuse Assembly	1	$11.93	Add to Cart
	PIN43	A Connection To The Allison “pto Enable This Location .	TCM	—	Call for availability
13	34M18250	Female Spade Connector (¼ ")	3	$2.93	Add to Cart
14	34M18009	Ring Terminal	2	$2.82	Add to Cart
15	30T60228	Pressure Switch	1	$172.61	Add to Cart
	34T36941	Wiring Pigtail With The “p” Special Feature	1	$38.67	Add to Cart
16	43T37385	Orifice Fitting	1	$15.23	Add to Cart
17	45M4R536	Lube Hose Assembly	1	$62.22	Add to Cart
18	30T35687	Rocker Switch 12V	1	$66.82	Add to Cart
19	36MA1005	Switch Bracket	1	$12.04	Add to Cart
20	36T36271	Face Plate	1	$5.11	Add to Cart
21	25T21684	Pipe Plug	1	$2.31	Add to Cart
	48TA3953	Sol Bracket Kit .	1	$17.17	Add to Cart

Electric/Air Shift System with System Protection Feature

Item	Part No.	Description	Qty	Price
1	44MB2164	Pipe Nipple	1	$5.22	Add to Cart
2	31M15759	Pressure Protection Valve	1	$120.08	Add to Cart
3	44MB6844	Fitting	2	$9.14	Add to Cart
4	45M44430	Tubing (30 Ft.)	1	$64.95	Add to Cart
5	35M30692	Street Tee	1	$314.26	Add to Cart
6	35M30962	12V Solenoid Valve	1	—	Call for availability
7	44MB6842	Fitting	2	$6.66	Add to Cart
8	44MB2252	Street Tee	1	$8.29	Add to Cart
9	44MB0942	Reducer Bushing	1	$3.90	Add to Cart
10	31M14732	Press. Safety Switch (no 80 Psi)	1	$87.43	Add to Cart
11	37T42512	Wire (12 Ft.)	1	$7.07	Add to Cart
12	33T36299	Fuse Assembly	1	$11.93	Add to Cart
13	34M18250	Female Spade Connector (¼ ")	3	$2.93	Add to Cart
14	34M18009	Ring Terminal For Footnotes 1 2 & 3. ,	2	$2.82	Add to Cart
15	30T60228	Pressure Switch	1	$172.61	Add to Cart
	34T36941	Wiring Pigtail With The “p” Special Feature	1	$38.67	Add to Cart
16	43T37385	Orifice Fitting	1	$15.23	Add to Cart
17	45MR536	Lube Hose Assembly	1	—	Call for availability
18	30T35687	Rocker Switch 12V	1	$66.82	Add to Cart
19	36MA1005	Switch Bracket	1	$12.04	Add to Cart
20	36M01006	Face Plate With Light Access	1	$7.62	Add to Cart
21	25T21684	Pipe Plug (included W/ Pto)	1	$2.31	Add to Cart
	222324ARE	Included In Kit 36TK4971	Items 20,	—	Call for availability
22	34M18002	Butt Splice	1	$2.93	Add to Cart
23	34M18187	Female Space Connector ( 3 ⁄16 ")	2	$3.30	Add to Cart
24	32MSR12V	Overspeed Light 12V	1	$14.21	Add to Cart
	43TA3953	Sol Bracket Kit .	1	—	Call for availability

Electric/Hydraulic Shift System

Item	Part No.	Description	Qty	Price
1	35M12340A	12V Solenoid Valve	1	$420.60	Add to Cart
2	34M18009	Ring Terminal	2	$2.82	Add to Cart
3	44MB2252	Street Tee	1	$8.29	Add to Cart
4	43T35867	Fitting	1	$10.92	Add to Cart
5	37T42512	Wire (12 Ft.)	1	$7.07	Add to Cart
6	33T36299	Fuse Assembly	1	$11.93	Add to Cart
7	34M18250	Female Spade Connector (¼ ")	3	$2.93	Add to Cart
8	30T60228	Pressure Switch	1	$172.61	Add to Cart
	34T36941	Wiring Pigtail	1	$38.67	Add to Cart
	PIN43	A Connection To The Allison “pto Enable This Location .	TCM	—	Call for availability
9	43T37385	Orifice Fitting	1	$15.23	Add to Cart
10	45M4R536	Lube Hose Assembly	1	$62.22	Add to Cart
11	30T35687	Rocker Switch 10V	1	$66.82	Add to Cart
12	36MA1005	Switch Bracket	1	$12.04	Add to Cart
13	36T36271	Face Plate	1	$5.11	Add to Cart
	19T36623	Capscrew	2	$2.30	Add to Cart
	22T35140	Hex Nut	2	$2.28	Add to Cart
	21T37991	Lock Washer	2	$2.41	Add to Cart

Electric/Hydraulic Shift System with System Protection Feature

Item	Part No.	Description	Qty	Price
1	35M12340A	12V Solenoid Valve	1	$420.60	Add to Cart
2	34M18009	Ring Terminal	2	$2.82	Add to Cart
3	44MB2252	Street Tee	1	$8.29	Add to Cart
4	43T35867	Fitting	1	$10.92	Add to Cart
5	37T42512	Wire (12 Ft.)	1	$7.07	Add to Cart
6	33T36299	Fuse Assembly	1	$11.93	Add to Cart
7	34M18250	Female Spade Connector (¼ ")	3	$2.93	Add to Cart
8	30T60228	Pressure Switch	1	$172.61	Add to Cart
	34T36941	Wiring Pigtail For Footnotes 1 2, 3, 4 & 5. ,	1	$38.67	Add to Cart
9	43T37385	Orifice Fitting	1	$15.23	Add to Cart
10	45M4R536	Lube Hose Assembly	1	$62.22	Add to Cart
11	30T35687	Rocker Switch 10V	1	$66.82	Add to Cart
12	36MA1005	Switch Bracket	1	$12.04	Add to Cart
13	36T36271	Face Plate	1	$5.11	Add to Cart
	19T36623	Capscrew	2	$2.30	Add to Cart
	22T35140	Hex Nut	2	$2.28	Add to Cart
	21T37991	Lock Washer	2	$2.41	Add to Cart

Electric/Hydraulic Shift System for Drop-In Solenoid Option

Item	Part No.	Description	Qty	Price
10	45T38840	36 " Hose Kit 48TK5106/48TK5115 -	1	$80.16	Add to Cart
	45T39186	17 " Hose Kit 48TK5111/48TK5112 -	1	$83.66	Add to Cart
	45T36274	28 " Hose Kit 48TK5113/48TK5117 -	1	$72.83	Add to Cart
11	43M05522	Orifice Fitting	1	$16.93	Add to Cart
	43T37385	Orifice Fitting	1	$15.23	Add to Cart
12	45M4R536	Lube Hose Assembly	1	$62.22	Add to Cart
13	30T35687	Rocker Switch 12V	1	$66.82	Add to Cart
14	36MA1005	Switch Bracket	1	$12.04	Add to Cart
15	36T36271	Face Plate	1	$5.11	Add to Cart
16	25T21684	Pipe Plug (included W/ Pto)	1	$2.31	Add to Cart
	43T36445	Elbow Fitting (use As Needed) The Vehicle Dealer Or Body	1	$15.10	Add to Cart

Electric/Hydraulic Shift System with System Protection Feature (for Drop-In Solenoid Option)

Item	Part No.	Description	Qty	Price
1	37T42512	Wire (12 Ft.)	1	$7.07	Add to Cart
2	33T36299	Fuse Assembly	1	$11.93	Add to Cart
3	34M18002	Butt Splice	1	$2.93	Add to Cart
4	34M18250	Female Spade Connector (¼ ")	1	$2.93	Add to Cart
5	34M18009	Ring Terminal	1	$2.82	Add to Cart
6	37T35674	Grommet	1	$2.82	Add to Cart
7	34T40902	Wire Harness	1	$119.03	Add to Cart
8	30T60223	Pressure Switch	1	$147.87	Add to Cart
9	43M68014	Fitting	1	$19.98	Add to Cart
10	45T38840	Hose Assembly (48TK5106 & 48TK5115)	1	$80.16	Add to Cart
	45T39186	Hose Assembly (48TK5111 & 48TK5112)	1	$83.66	Add to Cart
	45T36274	Hose Assembly (48TK5113 & 48TK5117)	1	$72.83	Add to Cart
11	43M05522	Orifice Fitting	1	$16.93	Add to Cart
12	45M4R536	Lube Hose Assembly	1	$62.22	Add to Cart
13	30T35687	Rocker Switch 12V	1	$66.82	Add to Cart
14	36MA1005	Switch Bracket	1	$12.04	Add to Cart
15	36M01006	Face Plate With Light Access	1	$7.62	Add to Cart
16	25T21684	Pipe Plug (included W/pto) Are Included In Kit 36TK4971	1	$2.31	Add to Cart
17	34M18187	Female Spade Connector (3 ⁄16 ")	2	$3.30	Add to Cart
18	34M18002	Butt Splice	1	$2.93	Add to Cart
19	32MSR12V	Overspeed Light 12V	1	$14.21	Add to Cart

Electric/Hydraulic “2” Shift System

Item	Part No.	Description	Qty	Price
1	30T60223	Pressure Switch	1 X X X X	$147.87	Add to Cart
	45T36274	28 " Hose Assembly	1 X X	$72.83	Add to Cart
	45T39186	17 " Hose Assembly	1 X X	$83.66	Add to Cart
3	43M68014	Fitting	1 X X X X	$19.98	Add to Cart
4	43T37385	Orifice Fitting	1 X X X X	$15.23	Add to Cart
5	43TK3934	Hose Kit	1 X X X X	$83.27	Add to Cart
6	25T21684	Pipe Plug (included W/pto)	1 X X X X	$2.31	Add to Cart
7	34T43466	Gm Wiring Harness	1 X X X X	$213.01	Add to Cart
8	43TK5157	Lube Tee Kit	1 X X X X	$235.39	Add to Cart
9	43T36445	Elbow Fitting	1 X X X X	$15.10	Add to Cart
10	43T36431	Fa-adapter	1 X X X X	$5.71	Add to Cart
	43M05522	Lube Fitting	1 X X X X	$16.93	Add to Cart

Feature Code “H ” Mounting Kits: 6-Bolt

Item	Part No.	Description	Qty	Price
1	20T37032	Step Stud	2	$16.80	Add to Cart
2	20M38150	Stud	4	$5.05	Add to Cart
3	22T39282	Spiralock Nut	4	$2.77	Add to Cart
4	22T37605	Whiz-lock Nut	2	$2.28	Add to Cart
	MC0002	Instruction Card With CS6B & CS6C (not A67)	1	—	Call for availability
1	20T37952	Step Stud	2	$13.58	Add to Cart
2	20M39040	Stud	4	$6.74	Add to Cart
1	20T38391	Step Stud	2	$21.35	Add to Cart
2	20M39045	Stud	4	$6.86	Add to Cart
1	20T64030	Alignment Stud	2	$27.53	Add to Cart
2	20T64008	Stud	4	$23.25	Add to Cart
	MC1801	Instruction Card Used With CS6F-F84**	1	—	Call for availability
	13M51717	Loctite Gasket Eliminator	1	$49.01	Add to Cart
	20TK5169	-		$51.04	Add to Cart
1	20T41354	Step Stud	2	$8.73	Add to Cart
2	20T37990	Stud	4	$8.10	Add to Cart
1	20T64076	Alignment Stud	2	—	Call for availability
2	20T64077	Stud	4	—	Call for availability
4	21T64303	Flat Washer	4	$3.65	Add to Cart
	MC1804	Instruction Card Used With CS6B-A6707	1	—	Call for availability
1	20T64085	Alignment Stud	2	—	Call for availability
2	20T64089	Stud	4	—	Call for availability

Accessory Kits

Item	Part No.	Description	Qty	Notes	Price
1	45M4R536	Hose Assembly Standard -	1		$62.22	Add to Cart
2	43M05522	Elbow	1		$16.93	Add to Cart

CS Low-Box and CSGB Low-Box

Item	Part No.	Description	Qty	Price
1	12T36872	O-ring	1	$18.06	Add to Cart
2	01T40900	Low-box Housing	1	—	Call for availability
3	25T34029	Cap Plug	1	$2.00	Add to Cart
4	21T36002	Washer	2	$2.82	Add to Cart
5	21T35233	Thrust Plate	2	$106.23	Add to Cart
6	19T35998	Capscrew	2	$8.68	Add to Cart
7	07TA4956	Input Assembly	1	$557.66	Add to Cart
8	10T35243	Bearing	3	$13.51	Add to Cart
9	21T35243	Thrust Race	2	—	Call for availability
10	10T27216	Bearing	1	$10.16	Add to Cart
11	26T01627	Woodruff Key	1	$5.78	Add to Cart
12	06TA3807	Output Shaft Assembly	1	$729.68	Add to Cart
13	10T35239	Bearing	1	$8.16	Add to Cart
14	21T35241	Thrust Race	1	$15.84	Add to Cart
15	10T35239	Bearing	4	$8.16	Add to Cart
16	15T35209	Low-box Cover	1	$264.55	Add to Cart
17	26T35232	Pin	2	$4.24	Add to Cart
18	19T32740	Hex Head Capscrew	8	$2.77	Add to Cart
19	11T37790	Seal	1	$13.58	Add to Cart
	13T35219	Gasket, Housing *supplied Csgb Low-box	1	$21.55	Add to Cart
1	43T37503	Jic Straight Fitting	1	$4.53	Add to Cart
2	43T36445	Jic Elbow Fitting	1	$15.10	Add to Cart
3	45T36308	Lube Hose	1	$54.78	Add to Cart
4	43T35867	Jic Elbow Fitting	1	$10.92	Add to Cart
5	43T37385	Orifice Elbow		$15.23	Add to Cart
6	43TK3934	Lubrication Hose Kit		$83.27	Add to Cart

Output Options

Part No.	Description	Qty	Price
1250RND	Shaft W/ 5 ⁄16 " Key “c ”	Output	—	Call for availability
DIN100	Companion Flange “d ”	Output	—	Call for availability
M12X1	.75-2B		—	Call for availability

Gasket Kits

Part No.	Description	Qty	Price
11T36124		1	$56.14	Add to Cart
11T37790		1	$13.58	Add to Cart
12T34003		1	$20.22	Add to Cart
12T35774		2	$4.42	Add to Cart
12T35949		2	$3.57	Add to Cart
12T36054		1	$14.04	Add to Cart
12T36471		2	$3.30	Add to Cart
12T36472		1	$12.75	Add to Cart
12T36751		1	$8.14	Add to Cart
13M35091		1	$2.33	Add to Cart
13M35092		1	$2.33	Add to Cart
16T41119		1	$28.62	Add to Cart
19T41118	Socket	4	$5.20	Add to Cart
CS6RBK03	CS6 03 &	(Ratio	$894.81	Add to Cart
CS6GSK	CS6	1	$149.04	Add to Cart
10T21017		2	$74.28	Add to Cart
10T34006		2	$36.00	Add to Cart
10T34620		2	$46.25	Add to Cart
10T36285		1	$60.48	Add to Cart
13M13541		1	$18.39	Add to Cart
18T34622		1	$22.88	Add to Cart
21T29017		2	$30.01	Add to Cart
21T34621		4	$16.91	Add to Cart
21T36511		1	$71.82	Add to Cart
24T27240		1	$8.86	Add to Cart
24T35480		2	$6.51	Add to Cart
24T36470		1	$2.28	Add to Cart
24T36894		1	$3.44	Add to Cart
27T36173		4	$4.40	Add to Cart
27T38791		2	$21.32	Add to Cart
49T33563		7	$12.04	Add to Cart
49T33564		8	$15.34	Add to Cart
13M35151	Gasket	1	$5.22	Add to Cart
13M35152	Gasket	1	$6.09	Add to Cart
CS6RBK05	CS6 Rebuild Kit (PRE-2012) Description	(RATIO 05-14	$902.86	Add to Cart
10T35776	Bearing	2	$54.96	Add to Cart
18T35781	Cone Spacer (SC306)	1	$15.47	Add to Cart
18T36229	Cone Spacer (SC306)	1	$17.50	Add to Cart
18T36230	Cone Spacer (SC306)	1	$17.50	Add to Cart
18T41439	Thrust Washer	1	$15.10	Add to Cart
18T41440	Thrust Washer	1	$15.10	Add to Cart
18T41441	Thrust Washer	1	$15.10	Add to Cart
18T41442	Thrust Washer	1	$15.10	Add to Cart
18T41443	Thrust Washer	1	$15.10	Add to Cart
18T41452	Thrust Washer 18T36229, 18T36230 ,	1	$15.10	Add to Cart

CS6 Rebuild Kits

Part No.	Description	Qty	Price
10T38248		1	$75.04	Add to Cart
11T64141		1	$18.33	Add to Cart
12T36053		2	$4.61	Add to Cart
13M35151		1	$5.22	Add to Cart
13M35152		1	$6.09	Add to Cart
24T36040		1	$6.09	Add to Cart
24T37951		1	$5.94	Add to Cart
27T36112		1	$12.84	Add to Cart
10T21017		11T37790, 12T36471	$74.28	Add to Cart
10T34006	Bearing	2	$36.00	Add to Cart
10T34620	Thrust Bearing	2	$46.25	Add to Cart
21T34621	Thrust Washer	4	$16.91	Add to Cart

CS8 Rebuild Kits

Part No.	Description	Qty	Price
CS8GSK	CS8	1	$156.42	Add to Cart
10T21017		2	$74.28	Add to Cart
10T34006		2	$36.00	Add to Cart
10T34620		2	$46.25	Add to Cart
10T36285		1	$60.48	Add to Cart
21T29017		2	$30.01	Add to Cart
21T34621		4	$16.91	Add to Cart
21T36511		1	$71.82	Add to Cart
24T35480		2	$6.51	Add to Cart
24T36470		1	$2.28	Add to Cart
24T36894		1	$3.44	Add to Cart
27T36112		1	$12.84	Add to Cart
27T36173		4	$4.40	Add to Cart
49T33563		7	$12.04	Add to Cart
49T33564		8	$15.34	Add to Cart
CS8RBK03IZ	CS8 (output	03 & 04)	$942.46	Add to Cart
10T38248		1	$75.04	Add to Cart
11T64141		1	$18.33	Add to Cart
12T36053		2	$4.61	Add to Cart
13M35151		1	$5.22	Add to Cart
13M35152		1	$6.09	Add to Cart
24T36040		1	$6.09	Add to Cart
24T37951		1	$5.94	Add to Cart
11T37790	27T38791	12T36471 13M13541	$13.58	Add to Cart
10T35776	Bearing	2	$54.96	Add to Cart
12T36472	O-ring	1	$12.75	Add to Cart
18T35781	Cone Spacer	1	$15.47	Add to Cart
18T36229	Cone Spacer	1	$17.50	Add to Cart
18T36230	Cone Spacer	1	$17.50	Add to Cart
24T27240	Snap Ring	1	$8.86	Add to Cart
CS8RBK05IZ	CS8 Rebuild Kit (output I, Z, D) Description CS8 Rebuild Kit (ratios 05-14)	05-14	$912.18	Add to Cart
18T41439		1	$15.10	Add to Cart
18T41440		1	$15.10	Add to Cart
18T41441		1	$15.10	Add to Cart
18T41442		1	$15.10	Add to Cart
18T41443		1	$15.10	Add to Cart
18T41452		1	$15.10	Add to Cart
13M35091		13M35092	$2.33	Add to Cart

CB6/8 Gasket & Rebuild Kits

Part No.	Description	Qty	Price
CS6GSK	CS6 Gasket Kit (less 12T36054)	1	$149.04	Add to Cart
12T35343	O-ring	2	$5.69	Add to Cart
12T39967	O-ring	1	$4.61	Add to Cart
CB6RBK03	CB6 Rebuild Kit 03 & 04) Description CS6 Rebuild Kit (less 12T36472)	(Ratio	$894.81	Add to Cart
24T24315	Snap Ring	1	—	Call for availability
27T40389	Spring	1	$55.44	Add to Cart
CB6RBK05	CB6 Rebuild Kit 05 & 14) Description CS6 Rebuild Kit (less 12T36472)	(Ratio	$902.86	Add to Cart
CB6RBK05A	CB6 Rebuild Kit 14) (2012+) Description CB6 Rebuild Kit	(Ratio 05 &	$930.29	Add to Cart
18T41439	Thrust Washer	1	$15.10	Add to Cart
18T41440	Thrust Washer	1	$15.10	Add to Cart
18T41441	Thrust Washer	1	$15.10	Add to Cart
18T41442	Thrust Washer	1	$15.10	Add to Cart
18T41443	Thrust Washer	1	$15.10	Add to Cart
18T41452	Thrust Washer 18T36229, 18T36230	1	$15.10	Add to Cart
CS8GSK	CS8 Gasket Kit	1	$156.42	Add to Cart
CB8RBK03	CB8 Rebuild Kit 03 & 04) Description CS8 Rebuild Kit	(Ratio	$996.78	Add to Cart
18T34622	Spacer	1	$22.88	Add to Cart
CB8RBK05	CB8 Rebuild Kit 05 & 14) Description CS8 Rebuild Kit (less 12T36472)	(Ratio	$957.52	Add to Cart
CB8RBK05A	CB8 Rebuild Kit 14) (2012+) Description CB8 Rebuild Kit	(Ratio 05 &	$1,008.03	Add to Cart

This is the complete factory parts breakdown for the Muncie PTO CB6 — every part in the manual, matched to our live inventory. We stock 459 of the 483 parts above; click any part number to view it, or add it straight to your cart. Click a number on any diagram to jump to that part.

No parts match that search — try the part number with no dashes.

This Muncie Parts & Service Manual covering the CB6 PTO helps you identify the correct gear sets, shifter kits and service parts for your power take-off before you order.

Models covered	CB6
PTO type	Muncie power take-off (PTO)
Document	Parts & Service Manual (Muncie)
Length	33 pages
Format	PDF — view below or download free

What’s inside

Gear sets & output shaft assemblies
Shifter & air-shift control kits
Mounting gaskets & adapter plates
Housings & cover assemblies
Seal, bearing & snap-ring kits
Application & ratio reference tables
Exploded views with OEM part numbers

Muncie parts & units we stock

Pro Gear and Transmission stocks new, remanufactured and good-used parts for Muncie PTO units:

Not sure exactly which unit you have? Check our identification guides, or Ask an Expert — send us photos of your data tag and our drivetrain specialists will identify the unit and the exact parts you need. Or call (877) 776-4600.
