The Muncie 03T37059 is the input gear for the M6509 power take-off, used in CS6 Series PTO units. Manufacturer service documents identify this part as a 26/26-tooth, 6.48 diametral pitch, 17.65° pressure angle spur gear. It is also cross-referenced as part of assembly 03TA4570 in Muncie's own service literature. The CS6 Series commonly fits Allison 1000/2000 automatic transmissions as well as many manual transmissions, offering six transmission input gear options across the series. Pro Gear and Transmission carries genuine Muncie parts. Call us to confirm proper fit for your specific PTO and transmission combination.
Features
Muncie CS6 Series M6509 input gear, part number 03T37059
26/26 tooth count, spur gear configuration
6.48 diametral pitch, 17.65° pressure angle
Cross-referenced in Muncie assembly 03TA4570
CS6 Series fits Allison 1000/2000 series and many manual transmissions
Genuine Muncie Power Products replacement part
Tech Specs
- Part Number: 03T37059
- Part Type: Input Gear
- Application: M6509 PTO (CS6 Series)
- Tooth Count: 26/26
- Diametral Pitch: 6.48P
- Pressure Angle: 17.65°
- Gear Form: Spur
- Assembly Cross-Reference: 03TA4570
Used in these Muncie PTO models
