The Muncie 47TA4159 is a G Shaft with an 05 speed ratio, belonging to Muncie's CS6/CS8 Series power take-off family. This series fits Allison 1000/2000 series automatic transmissions as well as many popular manual transmissions, and supports direct-mount pump options in SAE "A", "B", and "BB" as well as DIN 5462 configurations. At the 05 ratio, the CS6/CS8 Series is rated for 57 intermittent horsepower at 1,000 RPM, 300 lbs.ft. intermittent torque, and 210 lbs.ft. continuous torque. The series also incorporates Muncie's patented drag brake, which prevents shaft rotation when the PTO is in the OFF position. A genuine Muncie part available from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Muncie CS6/CS8 Series G Shaft, part number 47TA4159
05 speed ratio
Intermittent torque rating: 300 lbs.ft. at 1,000 RPM
Continuous torque rating: 210 lbs.ft.
Intermittent horsepower rating: 57 HP at 1,000 RPM
Compatible CS6/CS8 Series fits Allison 1000/2000 and many manual transmissions
Series supports SAE "A", "B", "BB", and DIN 5462 direct-mount pump configurations
Tech Specs
- Speed Ratio: 05
- Intermittent Horsepower (at 1,000 RPM): 57 HP (43 kW)
- Intermittent Torque: 300 lbs.ft. (407 NM)
- Continuous Torque: 210 lbs.ft. (285 NM)
- Series: Muncie CS6/CS8
- Part Type: G Shaft
