The Muncie 48TK6200 is the 6X Shift Option installation kit for the FR6Q Series Power Take-Off in diesel stationary applications. The FR6Q is a solenoid-activated PTO designed for 4x2 and 4x4 Ford Super Duty trucks, F-350 through F-550, using the Ford 6R140 automatic transmission, and may also be used on F-650 and F-750 trucks. In stationary mode, the FR6Q Series is rated for 39 intermittent horsepower and 200 lbs.ft. intermittent torque at 1,000 RPM. This install kit carries Muncie part number 48TK6200 and is identified in Muncie service parts document SP16-04_FR6Q_Service_Parts.pdf. Call us to confirm proper fit for your application.
Features
Muncie part number 48TK6200, identified as the 6X Shift Option in Muncie service parts documentation
Designed for the FR6Q Series Power Take-Off in diesel stationary applications
Fits 4x2 and 4x4 Ford Super Duty F-350 to F-550 with the Ford 6R140 automatic transmission
Compatible with F-650 and F-750 trucks as well
FR6Q Series stationary rating: 39 intermittent HP and 200 lbs.ft. intermittent torque at 1,000 RPM
Solenoid-activated PTO with preconfigured wiring harness integration
Tech Specs
- Shift Option: 6X
- Application: FR6Q Series Power Take-Off, Diesel Stationary
- Compatible Transmission: Ford 6R140 Automatic
- Compatible Vehicles: Ford F-350 to F-550 (4x2 and 4x4); F-650 and F-750
- Stationary Intermittent HP at 1,000 RPM: 39
- Stationary Intermittent Torque: 200 lbs.ft.
- Stationary Continuous Torque: 140 lbs.ft.
- Activation: Solenoid
