The Muncie SS66-U2X3-C00XX or SS66U2X3C00XX is a split shaft power take-off from Muncie's SS66 Series, designed to provide two 6-bolt PTO apertures where the main transmission lacks a second opening or where space restricts access to it. The unit uses the main vehicle driveshaft as its input and, when engaged, disconnects that driveshaft from the rear axle to route power to auxiliary equipment. The two 6-bolt openings are compatible with common PTO series including the TG and CS6. Engagement is via air shift or heavy-duty push/pull cable. The SS66 Series is rated for a maximum thru-shaft torque of 2,900 lb-ft and is typically applied on chassis up to Class 5. Call us to confirm proper fit for your application.
Features
Two 6-bolt PTO apertures accept common PTO series including TG and CS6
Uses the main vehicle driveshaft as input; disconnects rear axle when engaged
Engagement via air shift or heavy-duty push/pull cable
Maximum thru-shaft torque rating: 2,900 lb-ft
Through-shaft flanges: Spicer 1410 and 1500/1510 Series
Typically used on chassis up to Class 5; also deployable behind a single PTO for multiple PTO options
Tech Specs
- Maximum Thru-Shaft Torque: 2,900 lb-ft
- Through Shaft Flanges: Spicer 1410, 1500/1510 Series
- PTO Openings: Two 6-bolt apertures
- Compatible PTO Series: TG, CS6
- Engagement: Air shift or heavy-duty push/pull cable
- Typical Application: Chassis up to Class 5
