The Muncie SSV2-14X5-ADEXXX or SSV214X5ADEXXX is a split shaft power take-off from the Muncie SSV2 series, engineered for extremely heavy-duty applications. The SSV2 series supports a maximum thru-shaft torque of up to 21,600 lb-ft and a maximum PTO output torque of up to 940 lb-ft. Four PTO outputs are arranged two front and two rear, accepting SAE "B" through SAE "D" pump mounts and Spicer 1410 to 1500 companion flanges. Air-shift controls allow easy engagement, and individual output controls let each drive be activated independently for operational flexibility. Available in upright or horizontal mounting configurations. Call us to confirm proper fit for your application.
Maximum Torque (thru-shaft): Up to 21,600 lbs.ft.
Maximum PTO output torque: Up to 940 lbs.ft.
PTO Outputs (2-Front, 2-Rear): SAE "B" to "SAE "D" pump mounts Spicer 1410 to 1500 companion flanges
Features
SSV2 series split shaft PTO for extremely heavy-duty applications
Maximum thru-shaft torque up to 21,600 lb-ft
Maximum PTO output torque up to 940 lb-ft
Four outputs (2 front, 2 rear): SAE "B" through SAE "D" pump mounts, Spicer 1410 to 1500 companion flanges
Air-shift controls for easy activation
Clutch shift option allows individual output activation without stopping other drive functions
Upright or horizontal versions; frame mounting kit option with isolation mounts available
Tech Specs
- Maximum Torque (thru-shaft): Up to 21,600 lb-ft
- Maximum PTO Output Torque: Up to 940 lb-ft
- PTO Outputs: 4 total (2 front, 2 rear)
- Pump Mounts: SAE "B" through SAE "D"
- Companion Flanges: Spicer 1410 to 1500
- Shift Type: Air shift
- Mounting: Upright or horizontal; frame mounting kit with isolation mounts optional
Additional Information
Weight: 234 lbs. (SSH2) 255 lbs. (SSV2)Maximum Torque (thru-shaft): Up to 21,600 lbs.ft.
Maximum PTO output torque: Up to 940 lbs.ft.
PTO Outputs (2-Front, 2-Rear): SAE "B" to "SAE "D" pump mounts Spicer 1410 to 1500 companion flanges
Parts manual and diagrams: Muncie SSV Series PTO parts list with prices
