The Muncie SSV2-14X5-ECXLXX or SSV214X5ECXLXX is a splitshaft power take-off from Muncie Power's SSV2 Series, engineered for extremely heavy-duty applications. This unit features precision ground gearing for quiet, high-torque power delivery, with air-shift controls for straightforward activation. The SSV2 is available in upright or horizontal mounting orientations to suit your installation. Individual output controls allow multiple drives to be managed independently, and the clutch-shift option lets each output be activated without stopping other functions. A frame mounting kit option supports installation using isolation-type mounts. PTO outputs span SAE "B" to SAE "D" pump mounts and Spicer 1410 to 1500 companion flanges. Call us to confirm proper fit for your application.
Maximum Torque (thru-shaft): Up to 21,600 lbs.ft.
Maximum PTO output torque: Up to 940 lbs.ft.
PTO Outputs (2-Front, 2-Rear): SAE "B" to "SAE "D" pump mounts Spicer 1410 to 1500 companion flanges
Features
Air-shift controls for straightforward PTO activation
Precision ground gearing for quiet, high-torque power delivery
Upright or horizontal mounting orientations available
Individual output controls for multiple independent drives
Clutch-shift option: each output activated without stopping other functions
Frame mounting kit option using isolation-type mounts
Tech Specs
- Maximum Torque (Thru-Shaft): Up to 21,600 lb.ft.
- Maximum PTO Output Torque: Up to 940 lb.ft.
- PTO Outputs: 2-Front, 2-Rear
- Pump Mounts: SAE "B" to SAE "D"
- Companion Flanges: Spicer 1410 to 1500
- Shift Type: Air Shift
- Mounting Options: Upright or Horizontal; Frame Mounting Kit Available
Additional Information
Weight: 234 lbs. (SSH2) 255 lbs. (SSV2)Maximum Torque (thru-shaft): Up to 21,600 lbs.ft.
Maximum PTO output torque: Up to 940 lbs.ft.
PTO Outputs (2-Front, 2-Rear): SAE "B" to "SAE "D" pump mounts Spicer 1410 to 1500 companion flanges
