NTN 1380/1328 is a single row tapered roller bearing cone and cup set built from case carburized steel. The bore measures 0.875 in., with a 2.0625 in. outside diameter. Cone width is 0.7940 in. and cup width is 0.5625 in., and the set carries a dynamic load rating of 9100 lbf. This cone and cup pairing is sold as a matched set by Pro Gear and Transmission.
Features
Single row tapered roller bearing cone and cup set
Bore (ID): 0.875 in.
Outside diameter (OD): 2.0625 in.
Cone width: 0.7940 in.
Cup width: 0.5625 in.
Dynamic load rating: 9100 lbf
Case carburized steel construction
Tech Specs
- Bore (ID): 0.875 in.
- Outside diameter (OD): 2.0625 in.
- Cone width: 0.7940 in.
- Cup width: 0.5625 in.
- Dynamic load rating: 9100 lbf
- Row configuration: Single row
- Material: Case carburized steel
