NTN 30209P5 is a single row tapered roller bearing cone and cup set with a 45mm bore, 85mm outside diameter, and overall width of 20.75mm. The cone width measures 19.000mm and the cup width measures 16.000mm, with a dynamic load rating of 67500 N. It is made from case carburized steel for wear resistance at the rolling contact surfaces. This is a genuine NTN part from Pro Gear and Transmission.
Features
45 mm bore diameter
85.000 mm outside diameter
Overall width 20.75 mm
Cone width 19.000 mm, cup width 16.000 mm
Single row tapered roller design
Case carburized steel construction
Dynamic load rating 67500 N
Tech Specs
- Bore (ID): 45 mm
- Outside Diameter (OD): 85.000 mm
- Overall Width: 20.75 mm
- Cone Width: 19.000 mm
- Cup Width: 16.000 mm
- Dynamic Load Rating: 67500 N
- Type: Single Row Tapered Roller
- Material: Case Carburized Steel
