Choose your model or sub-category:

Bezares PTO Units & Parts (Eaton-Bezares)

Bezares builds power take-offs, hydraulic gear and dump pumps, wetline kits and the switches, seals and shift kits that keep them running. Units here carry Eaton-Bezares part numbers (PT-prefixed codes such as PT2000GAN011RA, also listed as 2000GAN011RA), so you can order by either. Choose a series from the tiles above, use the Bezares PTO parts manuals to read the model code on your unit, or call toll free at (877) 776-4600 and we will spec it for you.

Bezares PTO series we stock

Each series is sized to the transmission opening: 6-bolt and 8-bolt apertures on manual and automated-manual transmissions, 10-bolt on Allison automatics, 4-bolt rear-mount on Endurant. Hot-shift series engage electrically or over air; mechanical-shift series use a cable lever or air cylinder.

SeriesMountWhat it is
1000 / 10106-boltCast-iron 6-bolt PTO with 12 mm flange bolts for bigger pumps; wide choice of input gear, ratio, output and shifter. 1010 is the deep-mount version.
2000 / 20108-bolt8-bolt companion to the 1000: all cast iron, 12 mm flange bolts, the broadest ratio and output range in the line. 2010 covers Endurant.
30006-bolt, AllisonLow-profile 6-bolt PTO for Allison AT/MT/HT transmissions with several output, ratio and shift options.
313110-bolt, AllisonHeavy-duty 10-bolt Allison PTO rated 500 ft-lb / 97 HP at 1,000 rpm; single pressure hose, internal lubrication; 3131RP rear-pump option.
315110-bolt, Allison / CaterpillarConstant-mesh 10-bolt PTO for Allison and Caterpillar transmissions; wide ratio and output range.
32006-bolt, hot shiftAir-shifted hot-shift PTO for the 6-bolt aperture, built on the 1000/2000 gear train.
325210-bolt, AllisonMedium-duty low-profile Allison PTO; internal lubrication drops one hose. Wet-spline versions listed.
33006-bolt, hot shiftHot-shift PTO for the Allison 1000/2000 family and Aisin automatics; electric-over-hydraulic control.
3800 / 38108-bolt, hot shift8-bolt hot-shift unit developed from the 3200; air shifting, wide range of ratios, outputs and mounting positions.
3900 / 3920Ford TorqShiftHot-shift PTOs for Ford F-Series TorqShift transmissions, direct or remote-mount output.
4100 / 41108-bolt, heavy dutyCompact heavy-duty 8-bolt PTO with a 475 ft-lb torque rating; 4110 is the deep-mount version.
4250 / 42008-bolt, dual outputTwo independently air-operated outputs in one heavy-duty 8-bolt housing. Eaton Fuller transmissions only.
60006-bolt, forward/reverseMedium-duty forward-and-reverse PTO sharing the 1000/2000 input gears, so it fits most manual transmissions.
68008-bolt, forward/reverseAir-shift-only forward-and-reverse PTO with a 1.25 in round keyed output shaft.
80008-bolt, forward/reverseHeavy-duty 8-bolt forward-and-reverse PTO, air shift only, 1410-series companion flange output.
8500 / 85108-bolt, super heavy dutyMaximum-torque 8-bolt PTO, 10-20% lighter than equivalent units; 8510 covers Endurant.
95X4-bolt rear mount, EndurantLightest, most compact rear-countershaft PTO for Endurant; pneumatic shift, three internal ratios, offset to clear the pump.
120XRear mount, Detroit DT12Two-gear rear-mount PTO for the DT12 automated transmission; aluminum housing, pneumatic shift, four outputs, lube pump flange included.

Bezares wetline kits

A wetline (wet kit) is the hydraulic side of the installation: the tank, pump, valve, hoses and fittings that carry oil from the PTO-driven pump to the dump body or crane, packaged under one part number so nothing arrives mismatched. We stock the K-PTFWKC and K-PTEWKB families in 2-line and 3-line versions, starting with the K-PTFWKC2S wetline kit and the K-FWKC3S 3-line wetline kit, plus the Endurant XD end-dump kits K-PTYWKB3S (3-line, upright tank) and K-PTYWKB3U (3-line, saddle tank). Tell us the tank style and body and we will match the kit before it ships.

Bezares PTO parts

Everything that wears on a Bezares unit is in the Bezares Eaton PTO parts section: seal and gasket kits for every series (SK1000 through SK8500 plus the MK master rebuild kits), air-shift switches, hot-shift solenoids and coils, pressure switches, output shafts, input gears, hose kits, mounting and stud kits, and the switch kits for 2000/2010 and 8500/8510 units. We also carry the BEL, BEM and BEX gear pumps, BZ dump pumps in air- and manual-shift versions, and tandem vane pumps.

Where Bezares PTOs are used

Dump trucks and end dumps, roll-offs, cranes, vacuum and pumper trucks, walking floors, and any chassis that needs engine power at the transmission for a pump, blower or winch. Allison trucks take the 3000, 3131, 3151, 3252 and 3300 series; Eaton Fuller manuals and Endurant automated-manuals take the 1000, 2000, 4100, 8500 and 95X families; Ford TorqShift trucks take the 3900 and 3920.

In stock and ready to ship today

In-stock Bezares PTO units, pumps, wetline kits and parts ordered before our cutoff ship the same business day, worldwide. Not sure which series or ratio you need? Call toll free at (877) 776-4600 with your transmission model and what you need to run, and a PTO expert will confirm the fit before you buy.

!
