Wabco 4008653010 is an ECU E4C 4S/4M electronic control unit, type PABS ECU E4C, built to OE specification and rated for 12 V. The unit measures 184 x 57 x 216 mm and mounts on four 7.5 mm holes spaced 6.42 x 4.82 in apart.
It carries an IP 30 protection class (IEC 529) and a temperature range of -40°C to +75°C. Supersedes part number(s) S400-865-301-0.
A genuine Wabco part from Pro Gear and Transmission. Call us to confirm proper fit for your system.
A refundable core charge of $420.00 applies to this item and will be collected at checkout. The core charge is refunded upon receipt of your returned core, subject to its condition; customer is responsible for return shipping. Call us at (877) 776-4600 for details.
Features
System 4S/4M, type PABS ECU E4C
Voltage 12 V, OE specification
Mounting on four 7.5 mm holes, 6.42 x 4.82 in apart
IP 30 protection class (IEC 529)
Temperature range -40°C to +75°C
Size 184 x 57 x 216 mm
Tech Specs
- Brand WABCO
- Part type Premium original quality
- Product category Device
- Calculated Volume (dm³)2.265
- Distance between holes 6.42x4.82 in
- Mounting 4x Ø 7.5 mm
- Protection class IP 30 (IEC 529)
- System 4S/4M
- Technical specification OE specification
- Temperature range -40°C to +75°C
- Type PABS ECU E4C
- Voltage 12 V
- Size (mm x mm x mm)184 x 57 x 216
