The Wabco 4497111000 is a 2-pole wheel speed sensor extension cable designed to connect the wheel-end speed sensor to the ABS ECU. The cable measures 10 meters (32.81 ft) and features a straight WSS connector with a blunt cut end. The blunt cut design means trimming must be done from the blunt cut end only - do not splice the cable wires at any point along the run, as splicing compromises signal integrity. This two-wire cable is a genuine Wabco part, also cross-referenced as Wabco 8945900622. Available from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Non returnable item
Features
2-pole wheel speed sensor extension cable
Length: 10 meters (32.81 ft)
Straight WSS connector type
Blunt cut cable end - cut from blunt end only; do not splice wires
Connects wheel-end speed sensor to ABS ECU
Cross-references to Wabco 8945900622
Tech Specs
- Application: Connects wheel-end speed sensor to ABS ECU
- Type: 2-pole wheel speed sensor extension cable
- Connector Type: WSS - Straight
- Cable End: Blunt cut
- Length: 10 m (32.81 ft)
- Installation Note: Cut from blunt cut end only - do not splice cable wires
- Cross-Reference: Wabco 8945900622
