Meritor E5931-L or E5931L left hand wheel stud, sold as a 10 pack. It is a shoulder type stud with a clipped collar and plain serration, 4 1/2 in. overall, with 3/4-16 threads at both the hub end and the wheel end. The wheel end is left hand and carries 1.75 in. of thread; the hub end thread length is 1 3/16 in. A stud works like a stiff spring: tightening the nut stretches it slightly, and that tension is the clamping force that holds the wheel against the hub. Do not use it with a steel wheel, since the cap nut will bottom out before it tightens against the wheel. A genuine Meritor part from Pro Gear and Transmission.
This unit is sold in packs of 10.
Features
Left hand wheel end thread, 3/4-16, 1.75 in. thread length
Hub end thread 3/4-16, 1 3/16 in. thread length
Overall length 4 1/2 in., shoulder type, clipped collar, plain serration
Sold as a 10 pack
Not for use with a steel wheel, the cap nut bottoms out before tightening against the wheel
Replace a stud with damaged threads, a nut that will not spin on freely by hand, or a visibly narrowed shank
Tech Specs
- Wheel end thread: 3/4-16, left hand
- Wheel end thread length: 1.75 in.
- Wheel end length: 2 in.
- Hub end thread: 3/4-16
- Hub end thread length: 1 3/16 in.
- Hub end length: 2.38 in.
- Hub end body diameter: 0.786 in.
- Overall length: 4 1/2 in.
- Type: shoulder
- Collar style: clipped
- Collar diameter: 1.12 in.
- Collar length: 0.19 in.
- Collar across clip: 0.94 in.
- Serration: plain
- Unit pack: 10
