The Chelsea 272ZSJWX-P3XD is a 6-bolt hot shift power take-off from the Chelsea 272 Series. This unit is configured with pressure lubrication (P) and wet spline output (W), features that extend PTO and pump shaft service life in demanding duty cycles. The 272 Series supports intermittent torque ratings from 201 to 300 lb-ft and continuous-duty torque capability, with pneumatic or hydraulic shift options and an integral air control valve. Common applications across this series include aerial work platforms, construction equipment, water trucks, and towing and recovery rigs. Part number 272ZSJWX-P3XD is sold by Pro Gear and Transmission.
Features
6-Bolt mounting configuration
Hot shift operation with pneumatic or hydraulic shift
Integral air control valve included
Pressure lube (P) and wet spline (W) output configuration
Intermittent torque rating: 201-300 lb-ft (401-500 Nm)
Applicable to aerial, construction, water truck, and towing and recovery equipment
Tech Specs
- Mounting Type: 6-Bolt
- Shift Type: Pneumatic or Hydraulic (Hot Shift)
- Intermittent Torque: 201-300 lb-ft / 401-500 Nm
- Output Power: 56+ HP / 41-50 kW
- Lubrication: Pressure Lube
- Output: Wet Spline
- Series: Chelsea 272
Additional Information
Parts Manual: Chelsea 272 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
