The Chelsea 442 Series Power Take-Off, part number 442GHAHX-P3XK or 442GHAHXP3XK, is a 6-bolt mount PTO designed to fit virtually all existing 6-bolt transmission applications. The cast iron housing and tapered cone bearings on the output shaft deliver an intermittent torque rating of 201-300 lb-ft and output power in the 46-55 HP range, making it well-suited for tow trucks, dump trucks, service trucks, and small aerial trucks. This unit uses wire/cable mechanical shift and features a 1-1/4" round output shaft with a key. Rotatable output flanges aid installation clearance. Available from Pro Gear and Transmission - call us to confirm proper fit for your transmission and application.
Features
Chelsea 442 Series, 6-bolt transmission mount - fits virtually all existing 6-bolt applications
Cast iron housing with tapered cone bearings on the output shaft for long service life
Wire/cable mechanical shift
1-1/4" round output shaft with key
Intermittent torque rating: 201-300 lb-ft (339 Nm); output power: 46-55 HP
Rotatable output flanges for improved installation clearance
Tech Specs
- Mounting Type: 6-Bolt
- Shift Type: Wire/Cable, Mechanical
- Output Shaft Type: Round Shaft, 1-1/4" with Key
- Intermittent Torque: 201-300 lb-ft (339 Nm)
- Output Power: 46-55 HP (31-40 kW)
- Shaft Power: 24 HP at 500 RPM, 48 HP at 1000 RPM
- Housing Material: Cast Iron
- Bearing Type: Tapered Cone (output shaft)
- Dimensions (H x W x L): 8 in. x 10 in. x 14 in.
