The Chelsea 442 Series Power Take-Off, part number 442XHAHX-P3AF or 442XHAHXP3AF, is a 6-bolt mount PTO built for light-to-medium duty vocational applications. The cast iron housing and tapered cone bearings on the output shaft give the 442 Series its class-leading torque rating within the 201-300 lb-ft intermittent range. Output power runs 46-55 HP, with shaft power rated at 24 HP at 500 RPM and 48 HP at 1,000 RPM. The shift type on this unit is 12V electric/air shift. The output is an SAE B 2 or 4-bolt flange with a 1" 15-tooth SAE BB shaft. Typical applications include tow trucks, service trucks, dump trucks, and small aerial trucks. Call us to confirm proper fit for your transmission.
Features
Chelsea 442 Series, 6-bolt transmission mount
Cast iron housing with tapered cone bearings on output shaft
12V electric/air shift type
SAE B 2 or 4-bolt flange with a 1" 15-tooth SAE BB shaft
Intermittent torque rating: 201-300 lb-ft (339 Nm); output power 46-55 HP
Shaft power: 24 HP at 500 RPM, 48 HP at 1,000 RPM
Additional Information
Parts manual and diagrams: Chelsea 442 Series PTO parts list with prices
Equivalent PTOs:
Matched by full model number. Check the mounting, input gear and output against the unit you are replacing before you order. Look up any Chelsea, Muncie or Bezares number on our Muncie to Chelsea PTO cross reference.
