The Chelsea 442 Series Power Take-Off 442XLAHX-W6XK or 442XLAHXW6XK is a 6-bolt transmission-mount PTO with an air shift actuator and a 0.391:1 gear ratio. The output is a 1-1/4" round standard shaft, and the unit mounts with metric studs using the standard 6-bolt bolt pattern. No pressure lubrication is required. The cast iron housing and tapered cone bearings on the output shaft support the 442 Series intermittent torque rating and suit light-to-medium duty vocational work including dump trucks, service trucks, tow trucks, and small aerial applications. Rotatable output flanges simplify installation in tight clearance situations. Call us to confirm proper fit for your specific transmission.
Features
Product Series: Chelsea 442 Series PTO
Gear Ratio: 0.391:1
Shift Type: Air Shift
Output: 1-1/4" round standard shaft
Mounting: Standard 6-bolt mount with metric studs
Lubrication: No pressure lube required
Housing: Cast iron with tapered cone bearings on output shaft
Output flanges: 360-degree rotatable for improved installation clearance
Tech Specs
- Product Series: 442
- Gear Ratio: 0.391:1
- Shift Type: Air Shift
- Input Gear Designator: AH
- Mounting: Standard 6-bolt mount with metric studs
- Output: 1-1/4" round standard shaft
- Lubrication: No pressure lube
- Assembly: 3
