The Chelsea 885GMAHP-P3XV is an 885 Series Air PowerShift Power Take-Off built for heavy-duty applications on transmissions with an 8-bolt PTO aperture. Compatible transmission manufacturers for this series include Allison, Eaton/Fuller, and Volvo/Mack. The 885 Series is rated for intermittent torque up to 500 ft-lb (678 Nm) and supports continuous operation with a 30% de-rating. Output options include an SAE C pump flange (1-1/4 in. - 14-tooth spline) and a 1410 Series companion flange. The rugged cast-iron housing and heavy-duty ball bearings on the output shaft are built for demanding vocational cycles, including oil field, bulk transport, and fire and rescue applications. Call us to confirm proper fitment for your transmission and application.
Features
Chelsea 885 Series Air PowerShift (hydraulic shift) PTO
8-bolt mounting for compatible automatic and manual transmissions (Allison, Eaton/Fuller, Volvo/Mack and others)
Intermittent torque rating up to 500 ft-lb (678 Nm); continuous operation supported with 30% de-rating
SAE C output with 1-1/4 in. - 14-tooth pump spline; 1410 Series companion flange also available
Rugged cast-iron housing with heavy-duty ball bearings on the output shaft
Pressure lubrication available; Electric Overspeed Control (EOC) option offered in the 885 Series
Tech Specs
- Shift Type: Air PowerShift (Hydraulic)
- Mounting Type: 8-Bolt
- Intermittent Torque: Up to 500 ft-lb (678 Nm) - check application pages for actual torque ratings
- Continuous Operation: Yes, with 30% de-rating
- Output Type: SAE C Pump Flange; 1410 Series Companion Flange
- Output Shaft: SAE C - 1-1/4 in. - 14-tooth pump spline
- Output Power: 56+ HP (51+ kW)
- Shaft Power: 48 HP at 500 RPM; 95 HP at 1000 RPM
- Compatible Transmissions: Allison, Eaton/Fuller, Volvo/Mack, Other
- Housing Material: Cast iron
Additional Information
Parts manual and diagrams: Chelsea 885 Series PTO parts list with prices
