The Chelsea 272GSAJX-V5BV is a 272 Series hot shift power take-off assembly, also referenced as 272GSAJXV5BV. This 6-bolt PTO consolidates the earlier 230, 231, 236, 238, 270, and 271 Series into a single medium-duty platform. The 272 Series supports intermittent torque ratings from 201 to 300 lb-ft (401-500 Nm) and delivers 56-plus horsepower output. Shift type is either pneumatic or hydraulic, with an integral air control valve included. Common applications include towing and recovery, aerial equipment, construction equipment, and water trucks. Pro Gear and Transmission is your source for genuine Chelsea PTO assemblies. Call us to confirm proper fit for your application.
Features
Chelsea 272 Series 6-bolt mounting configuration
Hot shift design with pneumatic or hydraulic shift options
Intermittent torque rating: 201 to 300 lb-ft (401-500 Nm)
Output power: 56-plus HP (41-50 kW)
Includes integral air control valve
Compatible applications include towing and recovery, aerial, construction equipment, and water trucks
Tech Specs
- Mounting Type: 6-Bolt
- Shift Type: Pneumatic or Hydraulic
- Intermittent Torque: 201 to 300 lb-ft (401 to 500 Nm)
- Output Power: 56+ HP (41 to 50 kW)
- Series: Chelsea 272
- Part Number: 272GSAJX-V5BV or 272GSAJXV5BV
Additional Information
Parts Manual: Chelsea 272 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
