The Chelsea 442 Series Power Take-Off, part number 442GLJHX-A4XD or 442GLJHXA4XD, is a 6-bolt mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit uses air shift actuation and mounts via the standard configuration with metric studs. The output is a 1-1/4" round standard shaft, and the unit operates without a pressure lube system. The cast iron housing and tapered cone bearings on the output shaft contribute to the 442 Series' torque capacity and service life. Call us to confirm proper fit for your application.
Features
442 Series, 6-bolt transmission mount with metric studs
Air shift actuation
1-1/4" round standard output shaft
No pressure lube system
Cast iron housing with tapered cone bearings on output shaft
Tech Specs
- Product Series: 442
- Mounting Option: Standard Mount with Metric Studs (G)
- Gear Ratio Code: L (25/34)
- Input Gear Designator: JH
- Lube Option: No Pressure Lube (X)
- Shift Option: Air Shift (A)
- Assembly Arrangement: 4
- Output Option: 1-1/4" Round Standard Shaft with 5/16" Key (XD)
