The Chelsea 442 Series Power Take-Off, part number 442KXITX-A3XD or 442KXITXA3XD, is a 6-bolt mount PTO built around a cast iron housing with tapered cone bearings on the output shaft. This unit runs a 0.391:1 gear ratio, shifts via air, and delivers power through a 1-1/4" round standard output shaft. Mounting uses the standard configuration with metric studs. The lubrication setup is no-pressure lube. The 442 Series is suited for light-to-medium duty vocational applications including dump trucks, tow trucks, service trucks, and small aerial units. Call us to confirm proper fit for your specific transmission and application.
Features
Chelsea 442 Series, 6-bolt mounting with metric studs
Air shift operation
0.391:1 gear ratio
1-1/4" round standard output shaft (no-pressure lube)
Cast iron housing with tapered cone bearings on the output shaft
Low-profile shift cover; rotatable output flanges for improved clearance
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
- Mounting: 6-Bolt
