The Chelsea 442 Series Power Take-Off Assembly, part number 442XFDAX-A3XE or 442XFDAXA3XE, is a 6-bolt mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit runs a 0.391:1 gear ratio with air shift activation and delivers power through a 1-1/4" round standard output shaft. Mounting uses standard metric studs. The cast iron housing and tapered cone output shaft bearings are characteristic of the 442 Series, which the Parker Chelsea line rates for up to 250 lb-ft intermittent torque and shaft power of 48 HP at 1,000 RPM across the series. The no-pressure-lube configuration keeps the drivetrain simple. Call us to confirm proper fit for your application.
Features
Chelsea 442 Series, 6-bolt transmission mount with metric studs
Air shift activation
0.391:1 gear ratio
1-1/4" round standard output shaft
Cast iron housing with tapered cone output shaft bearings
Greaseable output shafts; rotatable output flanges for improved clearance
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
