The Chelsea 442 Series Power Take-Off, part number 442XQGRP-M3XD or 442XQGRPM3XD, is a 6-bolt mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit carries a 0.391:1 gear ratio with air shift actuation, a standard mount with metric studs, and a 1-1/4" round standard output shaft. The cast iron housing and tapered cone output shaft bearings are characteristic of the 442 Series, which the Parker Chelsea line rates for intermittent torque up to 250 lb-ft and output power from 46 to 55 HP. No-pressure-lube design simplifies installation. Call us to confirm proper fit for your transmission application.
Features
442 Series, 6-bolt mounting with metric studs (standard mount)
Gear ratio: 0.391:1
Shift type: air shift
Output: 1-1/4" round standard shaft
Cast iron housing with tapered cone output shaft bearings
No-pressure-lube design; greaseable output shaft for extended service life
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs
- Shift Type: Air Shift
- Output Shaft: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
