The Chelsea 442XUESX-A5XE or 442XUESXA5XE is a 442 Series Power Take-Off assembly configured with air shift, a 0.391:1 gear ratio, and a 1-1/4" round standard output shaft. It mounts via the standard 6-bolt pattern with metric studs and runs without pressure lubrication. The cast iron housing pairs with tapered cone bearings on the output shaft to support a torque range the 442 Series rates at up to 250 lb-ft intermittent. The 360-degree rotatable output flange and greaseable output shaft are built into this configuration. The 442 Series is designed for light-to-medium duty vocational work including service trucks, dump trucks, and tow trucks. Sold by Pro Gear and Transmission. Call us to confirm proper fit for your transmission application.
Features
Air shift actuation
0.391:1 gear ratio
1-1/4" round standard output shaft
Standard 6-bolt mount with metric studs
Cast iron housing with tapered cone bearings on output shaft
Rotatable output flange and greaseable output shaft
Tech Specs
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs (6-Bolt)
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
- Product Series: 442
