The Chelsea 489 Series Power Take-Off Assembly, part number 489GHITX-V3AZ or 489GHITXV3AZ, mounts directly to the 8-bolt PTO opening on compatible manual transmissions including Eaton Fuller, Volvo, Mack, and others - no adapter plate required. The one-piece cast iron housing eliminates a potential leak path and delivers the same intermittent torque capacity as the 442 Series: up to 250 lb-ft (339 Nm). Output is an SAE B 4-bolt flange with a 1-1/4" 14-tooth SAE C shaft. Shift is air shift. Shaft power ratings are 24 HP at 500 RPM and 48 HP at 1,000 RPM, with output power in the 46-55 HP range. Internal parts are shared with the 442 Series, simplifying parts sourcing. Call us to confirm proper fit for your application.
Features
8-bolt one-piece cast iron housing mounts directly to transmission opening - no adapter plate needed
Air shift; electric-over-air shift option available in the 489 Series
SAE B 4-bolt flange with a 1-1/4" 14-tooth SAE C shaft
Intermittent torque rating: 250 lb-ft (339 Nm) - same capacity as Chelsea 442 Series
Shaft power: 24 HP at 500 RPM, 48 HP at 1,000 RPM
Internal parts common to the 442 Series for simplified service; kit-style design for easy rebuild
Tech Specs
- PRODUCT SERIES: 489
- MOUNTING TYPE: 8-Bolt (direct mount, one-piece cast iron housing - no adapter plate)
- MOUNTING OPTION: Standard Mount with Metric Studs (G)
- GEAR RATIO CODE: H (23/35)
- INPUT GEAR DESIGNATOR: IT
- LUBE OPTION: No Pressure Lube (X)
- SHIFT OPTION: Air Shift without Installation Kit (V)
- ASSEMBLY ARRANGEMENT: 3
- OUTPUT OPTION: SAE B 4-Bolt Flange, SAE C Shaft (1-1/4" 14T) (AZ)
- INTERMITTENT TORQUE: 250 lb-ft (339 Nm) - Check Application Pages for Actual Torque Ratings
- CONTINUOUS TORQUE: De-rate intermittent torque rating by 30% - Check Application Pages for Actual Torque Ratings
- OUTPUT POWER: 46-55 HP (31-40 kW)
- SHAFT POWER: 24 HP (18 kW) at 500 RPM; 48 HP (36 kW) at 1,000 RPM
- TRANSMISSION COMPATIBILITY: Eaton/Fuller, Volvo/Mack, and other manual transmissions with 8-bolt PTO aperture
