The Chelsea 489 Series Power Take-Off, part number 489KFAHX-H3AF or 489KFAHXH3AF, mounts directly to an 8-bolt transmission opening on most manual transmissions including Eaton/Fuller, Volvo/Mack, and Tremec applications. The one-piece cast iron housing eliminates the need for an adapter plate, removing a potential leak path. Intermittent torque capacity for the 489 Series is 201-300 lb-ft (301-400 Nm); check application pages for the actual torque rating for your specific installation. Output is through an SAE B 2 or 4-bolt flange with a 1" 15-tooth SAE BB shaft. This unit has no shift assembly (ordered without a shifter). Shaft power is rated at 24 HP at 500 RPM and 48 HP at 1,000 RPM. Tapered output bearings replace the needle bearings found on earlier designs for greater load-bearing capability. Pro Gear and Transmission carries this genuine Chelsea unit. Call us to confirm proper fit for your application.
Features
489 Series one-piece cast iron housing bolts directly to 8-bolt transmission opening, no adapter plate needed
No shift assembly
Intermittent torque rating 201-300 lb-ft (301-400 Nm) for the 489 Series; verify actual torque for your specific application
SAE B 2 or 4-bolt flange with a 1" 15-tooth SAE BB shaft
Shaft power: 24 HP at 500 RPM, 48 HP at 1,000 RPM
Kit-style design with internal parts common to the Chelsea 442 Series simplifies service and parts sourcing
Tech Specs
- Product Series: 489
- Mounting Type: 8-Bolt
- Mounting Option: Standard Mount without Stud Kit (K)
- Gear Ratio Code: F (21/37)
- Input Gear Designator: AH
- Lube Option: No Pressure Lube (X)
- Shift Option: No Shift Assembly (H)
- Assembly Arrangement: 3
- Output Option: SAE B 2 or 4-Bolt Flange, SAE BB Shaft (1" 15T) (AF)
- Output Power: 46-55 HP (31-40 kW)
- Shaft Power: 24 HP at 500 RPM; 48 HP at 1,000 RPM (18 kW at 500 RPM; 36 kW at 1,000 RPM)
- Intermittent Torque: 201-300 lb-ft (301-400 Nm), check application pages for actual torque rating
- Continuous Torque: De-rate intermittent torque rating 30%, check application pages for actual torque rating
- Transmission Compatibility: Eaton/Fuller, Volvo/Mack, Tremec, and other 8-bolt manual transmissions
