The Chelsea 880 Series Power Take-Off, part number 880QGLZX-D3AF or 880QGLZXD3AF, is a heavy-duty 8-bolt PTO built for high-torque, high-demand applications including bulk haulers, fire trucks, oil field equipment, and large recovery trucks. It mounts to manual transmissions from Volvo/Mack, Allison, Eaton/Fuller, and others with an 8-bolt aperture. The output shaft is a 1-1/2"-10 spline with a 1410 companion flange, rated for intermittent torque up to 500 lb-ft (678 Nm). Shaft power is rated at 48 HP at 500 RPM and 95 HP at 1,000 RPM. The lever mechanical shift is standard. A cast iron housing and tapered cone bearings support heavy load cycles. The removable shift cover allows simpler, more accurate backlash adjustment during installation. Dual-pump output lets you mount a hydraulic pump on each end of the unit. Available from Pro Gear and Transmission. Call us to confirm proper fit for your transmission.
Features
8-bolt mounting fits most manual transmissions with an 8-bolt aperture, including Volvo/Mack, Allison, and Eaton/Fuller
Lever mechanical shift standard; output rated at 48 HP at 500 RPM and 95 HP at 1,000 RPM
1-1/2"-10 spline output shaft with 1410 series companion flange
Intermittent torque rating up to 500 lb-ft (678 Nm) - check application pages for actual torque rating
Dual-pump output allows a hydraulic pump to be mounted on each end of the PTO
Removable shift cover simplifies backlash adjustment for faster, more accurate installation
Tech Specs
- INTERMITTENT TORQUE: 500 lb-ft / 678 Nm (Check Application Pages for Actual Torque Ratings)
- SHIFT TYPE: Lever Mechanical
- MOUNTING TYPE: 8-Bolt
- OUTPUT SHAFT TYPE: 1-1/2" - 10T Spline with 1410 Series Companion Flange
- OUTPUT POWER: 56+ HP / 51+ kW
- SHAFT POWER: 48 HP at 500 RPM, 95 HP at 1,000 RPM (36 kW at 500 RPM, 71 kW at 1,000 RPM)
- TRANSMISSION MANUFACTURER: Volvo/Mack, Allison, Eaton/Fuller, Other
Additional Information
Parts Manual: Chelsea 880 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
