The Chelsea 880 Series Power Take-Off, part number 880QJLZX-D3XK or 880QJLZXD3XK, is an 8-bolt, bottom-mounted PTO built for heavy-duty applications including bulk haulers, fire trucks, oil field equipment, aerial units, and large recovery trucks. It uses a lever mechanical shift and delivers a 1-1/2"-10 spline output shaft with a 1410 companion flange, rated for up to 500 lb-ft intermittent torque. Shaft power runs 48 HP at 500 RPM and 95 HP at 1000 RPM. The 880 Series fits a wide range of transmissions, including Eaton/Fuller, Volvo/Mack, and Allison. A removable shift cover simplifies backlash adjustment. Available from Pro Gear and Transmission - call us to confirm proper fit for your application.
Features
8-Bolt mounting for compatibility with a wide range of manual transmissions including Eaton/Fuller, Volvo/Mack, and Allison
Lever mechanical shift with removable shift cover for straightforward backlash adjustment
1-1/2"-10T spline output shaft with 1410 companion flange
Intermittent torque rating up to 500 lb-ft (678 Nm) - check application pages for actual torque ratings
Shaft power: 48 HP at 500 RPM, 95 HP at 1000 RPM
Cast iron housing with dual-pump output capability for mounting a pump on each end of the PTO
Tech Specs
- Intermittent Torque: Up to 500 lb-ft (678 Nm) - check application pages for actual torque ratings
- Shift Type: Lever Mechanical
- Mounting Type: 8-Bolt
- Output Shaft Type: 1-1/2" - 10T Spline with 1410 Companion Flange
- Output Power: 56+ HP (51+ kW)
- Shaft Power: 48 HP (36 kW) at 500 RPM; 95 HP (71 kW) at 1000 RPM
- Transmission Compatibility: Eaton/Fuller, Volvo/Mack, Allison, Other
- Mounting Position: Bottom Mounted
- Dimensions (H x W x L): 15.75" x 12.5" x 14"
Additional Information
Parts Manual: Chelsea 880 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
