The Chelsea 880 Series Power Take-Off, part number 880QJLZX-D3XY or 880QJLZXD3XY, is an 8-bolt, heavy-duty PTO built for high-torque, high-cycle applications. It uses a lever-mechanical shift and delivers an intermittent torque rating of up to 500 lb-ft (678 Nm). Shaft power output reaches 48 HP at 500 RPM and 95 HP at 1,000 RPM. The output shaft is a 1-1/2"-10 spline configuration with a 1410 companion flange. Cast iron housing, tapered cone bearings, and a removable shift cover for straightforward backlash adjustment are standard across the 880 Series. Compatible with a broad range of manual transmissions on an 8-bolt aperture. Call us to confirm proper fit for your application.
Features
8-bolt mounting fits most manual transmissions with an 8-bolt aperture
Lever-mechanical shift as standard; optional air control shift available on the 880 Series
1-1/2" - 10-spline output shaft with 1410 companion flange
Intermittent torque rating up to 500 lb-ft (678 Nm); check application pages for actual torque ratings
Shaft power: 48 HP (500 RPM) and 95 HP (1,000 RPM)
Dual-pump output allows mounting a hydraulic pump on each end of the PTO
Tech Specs
- Intermittent Torque: 401-500 lb-ft / 501+ Nm (500 lb-ft / 678 Nm - check application pages for actual torque ratings)
- Transmission Compatibility: Volvo/Mack, Allison, Eaton/Fuller, Other (8-bolt aperture manual transmissions)
- Shift Type: Lever Mechanical
- Output Power: 56+ HP / 51+ kW
- Output Shaft Type: 1-1/2" - 10T Spline with 1410 Companion Flange
- Mounting Type: 8-Bolt
- Shaft Power: 48 HP (500 RPM) / 95 HP (1,000 RPM) | 36 kW (500 RPM) / 71 kW (1,000 RPM)
- Continuous Operation: Yes, with 30% de-rating
Additional Information
Parts Manual: Chelsea 880 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
