The Chelsea 880 Series Power Take-Off, part number 880XGAKP-M5AF or 880XGAKPM5AF, is an 8-bolt, lever mechanical shift PTO rated for up to 500 lb-ft intermittent torque (678 Nm). The output shaft is a 1-1/2"-10T spline with a 1410 companion flange, and the unit supports dual-pump output so a hydraulic pump can be mounted on each end. Shaft power is rated at 48 HP at 500 RPM and 95 HP at 1000 RPM. Compatible with Volvo/Mack, Allison, and Eaton/Fuller transmissions, among others, this PTO suits heavy-duty applications including fire trucks, bulk haulers, oil field equipment, and large recovery vehicles. The removable shift cover makes backlash adjustment straightforward. Call us to confirm proper fit for your specific transmission.
Features
8-bolt mounting pattern fits most manual transmissions from Volvo/Mack, Allison, and Eaton/Fuller
Lever mechanical shift with removable shift cover for easier, more accurate backlash adjustment
1-1/2"-10T spline output with 1410 companion flange
Dual-pump output allows a hydraulic pump to be mounted on each end of the PTO
Intermittent torque rating up to 500 lb-ft (678 Nm); check application pages for actual torque ratings
Shaft power: 48 HP at 500 RPM, 95 HP at 1000 RPM
Rugged cast iron housing
Tech Specs
- Intermittent Torque: 500 lb-ft / 678 Nm (check application pages for actual torque ratings)
- Shift Type: Lever Mechanical
- Mounting Type: 8-Bolt
- Output Shaft Type: 1-1/2" - 10T Spline with 1410 Companion Flange
- Output Power: 56+ HP / 51+ kW
- Shaft Power: 48 HP at 500 RPM; 95 HP at 1000 RPM (36 kW at 500 RPM; 71 kW at 1000 RPM)
- Transmission Compatibility: Volvo/Mack, Allison, Eaton/Fuller, Other
- Housing Material: Cast Iron
