The Chelsea 890HEFJW-B5XK or 890HEFJWB5XK is a hydraulic PowerShift Power Take-Off designed specifically for Allison 3000 MD and 4000 HD Series transmissions. It uses a 10-bolt mounting configuration and features an SAE C (XS) output shaft with Wet Spline Technology to reduce wear on mating pump splines in demanding duty cycles. The 890 Series moves the PTO/pump mounting flange to the rear of the transmission, giving better clearance between the pump and frame rail. A one-piece main shaft eliminates the input splines found on traditional PTO-plus-extension setups, and the clutch sits at the rear of the housing to allow the gear section to tuck tightly to the transmission. Continuous torque rating for the 890 Series reaches up to 670 ft-lb, with intermittent torque rated at 501+ ft-lb. Shaft power output is 64 HP at 500 RPM and 128 HP at 1,000 RPM. Typical applications include aerial trucks, fire and rescue, refuse trucks, and truck cranes. A genuine Chelsea part from Pro Gear and Transmission. Call us to confirm proper fit for your specific Allison transmission configuration.
Features
Fits Allison 3000 MD and 4000 HD Series transmissions via 10-bolt mount
Hydraulic PowerShift (hot shift) engagement
SAE C (XS) output shaft with Wet Spline Technology for extended pump spline life
Continuous torque rating up to 670 ft-lb; intermittent torque 501+ ft-lb
Shaft power: 64 HP at 500 RPM, 128 HP at 1,000 RPM
One-piece main shaft design eliminates input splines between PTO and output extension
Tech Specs
- Transmission Application: Allison 3000 MD and 4000 HD Series
- Product Series: 890
- Mounting Type: 10-Bolt
- Shift Type: Hydraulic PowerShift
- Output Shaft Type: SAE C (XS)
- Lubricant: Wet Spline
- Outlet Flange Type: SAE C
- Continuous Torque: 670 ft-lb (check application pages for actual torque ratings)
- Intermittent Torque: 501+ ft-lb
- Output Power: 56+ HP (51+ kW)
- Shaft Power: 64 HP at 500 RPM, 128 HP at 1,000 RPM (48 kW at 500 RPM, 95 kW at 1,000 RPM)
