The Eaton Easy Pedal Advantage clutch, part number 308925-24 or 30892524, is a 15.5-inch manual-adjust, heavy-duty clutch rated at 1750 ft-lb of torque. It uses a ceramic facing material with 4 friction pads across 2 discs and a 7-spring damper assembly. The input shaft is sized at 2.00 inches with a 10-spline count, and the unit does not include a pre-damper or hydraulic linkage. Dimensions are 17 inches in diameter by 7.25 inches tall. Call us to confirm proper fit for your application.
Interchanges:
- 208925-24
Shipped on pallet.
Features
15.5-inch clutch diameter rated at 1750 ft-lb torque
2-disc configuration with 4 ceramic friction pads
2.00-inch diameter, 10-spline input shaft
7-spring damper assembly; no pre-damper
Manual adjust; no hydraulic linkage
Heavy-duty vehicle classification, Eaton "Best" portfolio rating
Tech Specs
- CLUTCH SIZE: 15.5 in
- TORQUE RATING: 1750 ft-lb
- INPUT SHAFT SIZE: 2.00 in diameter, 10-spline
- NUMBER OF DISCS: 2
- FRICTION PAD COUNT: 4
- FACING MATERIAL: Ceramic
- DAMPER SPRING COUNT: 7
- PRE-DAMPER: No
- HYDRAULIC LINKAGE: No
- TRANSMISSION TYPE: Manual
- VEHICLE CLASSIFICATION: Heavy Duty
- PORTFOLIO RATING: Best
- DIMENSIONS (H x W x L): 7.25 in x 17 in x 17 in
