Meritor Front Hub Assembly P/N: 05-16026-002 or 0516026002

05-16026-002 Meritor Front Hub Assembly

Meritor

HYDRAULIC BRAKE - HUB ASSEMBLY

Listing Price: $1,393.19
Sale Price: $927.87

This item qualifies for FREE shipping on orders over $295 and under 70 lbs

(No reviews yet) Write a Review
Product Code:
MER0516026002
UPC:
680502509739
Condition:
New
Availability:
Usually Ships in 3 to 5 Business Days
Adding to cart… The item has been added
The Meritor 05-16026-002 or 0516026002 is a conventional-style front steer hub assembly for the FL axle series, rated at 23,000 lb GAWR. It includes a tone ring (ABS ring number 09-002166, ABS pilot diameter 6.546/6.543 in.) and is supplied as a hub-only unit without studs pre-installed. The 10-stud, 11.25 in. bolt circle accommodates a drum pilot diameter of 8.778/8.775 in. and a wheel pilot diameter of 8.653/8.646 in. Inner cone is 6461A, outer cone 555S, inner cup 6420, outer cup 552A. Hub cap bolt thread is 5/16-18 UNC-2B on a 5.50 in. hub cap bolt circle, hub cap pattern 06. Call us to confirm proper fit for your application.
Interchanges:
  • 82350516026002
  • HR0516026002
  • TDA0516026002

Non returnable item

Features

Axle application: Steer, Axle Series: FL, Hub Style: Conventional (hub only, not fully dressed)
GAWR: 23,000 lb
Tone ring included; ABS ring number 09-002166, ABS pilot diameter 6.546/6.543 in.
10-stud wheel and drum bolt pattern; 11.25 in. bolt circle diameter; stud hole .904/.906 in.
Bearing set: inner cone 6461A, inner cup 6420, outer cone 555S, outer cup 552A
Oil seal references A1205M1339 and A1205S2307; hub cap bolt thread 5/16-18 UNC-2B

Tech Specs

  • Hub Type: Hub Only (not fully dressed)
  • Hub Style: Conventional
  • Axle Application: Steer
  • Axle Series: FL
  • GAWR: 23,000 lb
  • Brake Type: Drum
  • Tone Ring: Yes
  • ABS Ring Number: 09-002166
  • ABS Pilot Diameter: 6.546/6.543 in.
  • Wheel Stud Pattern: 10
  • Wheel Stud Bolt Circle Diameter: 11.25 in.
  • Wheel Stud Hole: .904/.906 in.
  • Wheel Stud: 09-001727
  • Wheel Pilot Diameter: 8.653/8.646 in.
  • Drum Bolt Pattern: 10
  • Drum Bolt Circle Diameter: 11.25 in.
  • Drum Bolt Size: .904/.906 in.
  • Drum Pilot Diameter: 8.778/8.775 in.
  • Flange Outer Diameter: 13.215 in.
  • Inner Bearing Surface (IBS) to Mounting Face: 4.42 in.
  • IBS to OBS: 3.041/3.021 in.
  • IBS to Outer Surface: 4.851/4.831 in.
  • Inner Cone: 6461A
  • Inner Cup: 6420
  • Outer Cone: 555S
  • Outer Cup: 552A
  • Oil Seal: A1205M1339; A1205S2307
  • Hub Cap Pattern: 06
  • Hub Cap Bolt Circle Diameter: 5.50 in.
  • Hub Cap Bolt Thread: 5/16-18 UNC-2B
  • Base Part Number: 16026
  • VMRS Code: 018-001-003

Additional Information

Also referenced in Meritor catalog PB2006 (Meritor Drums, Hubs and Rotors Product Catalog).
!
