The Muncie 06TA10363 is a three-piece extension shaft assembly for the Muncie EX Drive system, identified in Muncie's own service-parts documentation as a DIN-5462, 8-spline shaft, 22.7 inches long, cross-referenced as XS10-A40XX-X*IIX*. The EX Drive series is engineered to mount directly to Allison 3000 and 4000 series transmissions equipped with a retarder or cooler, eliminating the need for a separate driveline installation. The three-piece shaft design is specific to this series and is intended to simplify assembly. It features a wet spline design for extended spline durability and a steel housing system. Compatible with both clutch-shift and constant-drive PTOs in the A40 family. Call us to confirm proper fit for your application.
Features
DIN-5462 output standard, 8-spline configuration
22.7-inch shaft length (XS10-A40XX series)
Three-piece shaft construction for simplified assembly
Wet spline design for extended spline durability
Steel housing system
Compatible with Allison 3000 and 4000 series transmissions with retarder or cooler
Tech Specs
- Output Standard: DIN-5462
- Spline Count: 8
- Shaft Length: 22.7 in.
- Series Cross-Reference: XS10-A40XX-X*IIX*
- Shaft Configuration: Three-piece assembly
- Spline Design: Wet spline
- Housing Material: Steel
