The Muncie 02T38992 is the 09-ratio (30T) "I" and "Z" output gear assembly for the CS6/CS8 series power take-off. Muncie's own service parts document SP96-05 identifies this as the output component carrying the 09-ratio 30-tooth gear configuration, distinguishing it from the companion 05-ratio 38-tooth assembly in the same series. The CS6/CS8 series is designed for direct-mount pump applications and fits Allison 1000/2000 series transmissions as well as many manual transmissions. Call us to confirm this assembly is the correct ratio and output configuration for your specific PTO build.
Features
09-ratio (30T) gear configuration for CS6/CS8 series PTO
"I" and "Z" output shaft compatibility
Muncie CS6/CS8 series fits Allison 1000/2000 series and many manual transmissions
Direct-mount pump options in SAE "A", "B", and "BB" and DIN 5462 flanges
Rotatable direct-mount flanges allow pump positioning for clearance
Muncie patented drag brake prevents shaft rotation in OFF mode
Tech Specs
- Ratio Designation: 09
- Gear Tooth Count: 30T
- Output Configuration: "I" and "Z" output
- Series: Muncie CS6/CS8 Power Take-Off
- Transmission Compatibility: Allison 1000/2000 series and many manual transmissions
- Direct Mount Pump Standards: SAE "A", "B", "BB"; DIN 5462
