NTN 02476/02420 or 0247602420 cone and cup bearing set is built from case carburized steel for a 1.25 in. bore. The cup outside diameter measures 2.6875 in., with a cone width of 0.8750 in. and a cup width of 0.6875 in. This set carries a dynamic load rating of 12,800 lbf, giving it the load capacity needed for heavy-duty rotating assemblies. Pro Gear and Transmission sells this matched cone and cup as a complete set.
Features
Case carburized steel construction
1.25 in. bore (ID)
2.6875 in. cup outside diameter
0.8750 in. cone width
0.6875 in. cup width
12,800 lbf dynamic load rating
Tech Specs
- Bore (ID): 1.25 in.
- Outside diameter (OD): 2.6875 in.
- Cone width: 0.8750 in.
- Cup width: 0.6875 in.
- Dynamic load rating: 12,800 lbf
- Material: Case carburized steel
