The Chelsea 287GTFJW-M3RK (also referenced as 287GTFJWM3RK) is a 10-bolt power take-off unit with pneumatic, constant-mesh shift. It mounts to Allison and other compatible transmissions using a 10-bolt (or 8-bolt) bolt pattern and delivers power through a 1-1/4-inch round output shaft with optional keyed configuration. Continuous-duty torque rating reaches up to 390 ft-lbs, with intermittent torque ratings in the 340 ft-lbs range (verify actual values on Chelsea application pages for your specific installation). Shaft power output is rated at 65 HP at 1,000 RPM. Rotatable output flanges allow clearance adjustments during installation, and a positive-stop feature protects driveline seals. Call us to confirm proper fit for your application.
Features
10-bolt mounting pattern, compatible with Allison and other transmissions
Pneumatic, constant-mesh shift operation
1-1/4" round output shaft, available with keyed configuration
Continuous-duty torque rating up to 390 ft-lbs
Rotatable output flanges for improved installation clearance
Positive-stop driveline feature to prevent seal damage
Tech Specs
- Mounting Type: 10-Bolt (8-Bolt also listed)
- Shift Type: Pneumatic, Constant Mesh
- Transmission Compatibility: Allison and other compatible transmissions
- Output Shaft Type: 1-1/4" Round; 1-1/4" Round with key
- Continuous-Duty Torque Rating: Up to 390 ft-lbs
- Intermittent Torque: 340 ft-lbs / 461 Nm (check Chelsea application pages for actual rating)
- Output Power: 56+ HP (41-50 kW)
- Shaft Power at 1,000 RPM: 65 HP / 48 kW
- Shaft Power at 500 RPM: 32 HP / 24 kW
