The Chelsea 288 Series Power Take-Off, part number 288GCFJP-M5XV or 288GCFJPM5XV, is a heavy-duty 10-bolt constant mesh PTO built on the 281 Series platform. It delivers a single, continuous duty torque rating of up to 390 lb-ft, made possible by wider gears and larger-capacity bearings than the 287 Series it replaces. The ductile iron bearing caps are 117% stronger than gray iron, and an O-ring sealing configuration between the housing and bearing cap improves clamp load and resists vibrational stress from modern engine designs. The round output shaft features a positive stop to prevent oil seal damage from driveline couplings. Nine speed ratios cover both low and high ranges. Wet Spline Lubrication is available, providing 7 to 10 times greater pump shaft life. Call us to confirm proper fit for your application.
Features
10-bolt constant mesh mounting on a cast iron housing
Continuous duty torque rating up to 390 lb-ft (series characteristic)
Ductile iron bearing caps, 117% stronger than gray iron predecessor
O-ring seal between housing and bearing cap reduces vibrational effects and improves clamp load
Round output shaft with positive stop eliminates oil seal damage from driveline couplings
Wet Spline Lubrication option extends pump shaft life 7 to 10 times
Nine speed ratios available, including low and high speeds
Hose included, no need to order separately
Tech Specs
- Mounting Type: 10-Bolt
- Shift Type: Constant Mesh
- Output Shaft Type: Round Shaft (1-1/4" Key)
- Continuous Duty Torque: Up to 390 lb-ft (series rating; verify for specific application)
- Intermittent Torque: 340 lb-ft (series rating; verify for specific application)
- Speed Ratios: Nine, including low and high
- Lubrication Options: Pressure Lube (P) or Wet Spline (W)
- Housing Material: Cast Iron
- Bearing Caps: Ductile Iron
