The Chelsea 288GGFJP-M8RF or 288GGFJPM8RF is a 10-bolt, constant mesh Power Take-Off from Chelsea's heavy-duty 288 Series. Built on the 281 Series platform, the 288 Series delivers a single continuous duty torque rating of up to 390 lb-ft, with nine available speed ratios spanning both low and high ranges. The cast iron housing and ductile iron bearing caps -- 117% stronger than gray iron -- address the vibrational demands of modern engine designs. The standard output features a positive-stop design that protects the oil seal from shaft coupling damage. A Wet Spline Lubrication option is available, extending pump shaft life by 7 to 10 times. Call us to confirm proper fit for your application.
Features
10-Bolt constant mesh PTO built on the 288 Series heavy-duty platform
Continuous duty torque rating of up to 390 lb-ft
Ductile iron bearing caps rated 117% stronger than gray iron
O-ring sealing configuration between housing and bearing cap improves clamp load and reduces vibrational effects
Positive-stop output shaft eliminates oil seal damage from driveline couplings
Wet Spline Lubrication option extends pump shaft life by 7 to 10 times; hose included
Tech Specs
- Mounting Type: 10-Bolt
- Shift Type: Constant Mesh
- Continuous Duty Torque Rating: Up to 390 lb-ft
- Output Shaft Type: Round shaft with 1-1/4" key
- Speed Ratios: Nine ratios available, including low and high speeds
- Lubrication Options: Pressure lube or Wet Spline
- Housing Material: Cast iron
- Bearing Caps: Ductile iron
