The Chelsea 210FMMFP-B255 or 210FMMFPB255 PTO assembly is a 210 Series power takeoff built for Ford transmissions with a Ford 10-bolt mounting pattern. It uses a hydraulic shift and a 46-tooth spur input gear driving an M gear ratio of 46/36 for 144% output speed. Intermittent torque is rated up to 235 lb-ft (319 Nm). The output is configurable with a 1-1/4" keyed shaft, a 3/4" 11-tooth SAE A pilot, or a 7/8" 13-tooth SAE A pilot. Internal lubrication is built in. This is a genuine Chelsea part from Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Fits Ford transmissions with a Ford 10-bolt mounting pattern
Hydraulic shift type
46-tooth spur input gear, M ratio 46/36 for 144% output speed
Intermittent torque up to 235 lb-ft (319 Nm)
Output options: 1-1/4" keyed, 3/4" 11T SAE A pilot, or 7/8" 13T SAE A pilot
Internal lubrication
Tech Specs
- PRODUCT SERIES: 210
- TRANSMISSION MANUFACTURER: Ford
- INTERMITTENT TORQUE: Up to 235 lb/ft Up to 319 Nm
- OUTPUT SHAFT TYPE: 1-1/4" Keyed, 3/4" 11T SAE A Pilot, 7/8" 13T SAE A Pilot
- SHIFT TYPE: Hydraulic
- WEIGHT: 35 lbs 16 kg
- GEAR RATIO: M = 46/36 (144% Output Speed)
- INPUT GEAR DESIGNATOR: MF = 46 Tooth Spur
- LUBRICANT: P = Internal Lubrication
- MOUNTING TYPE: Ford 10 Bolt
Additional Information
Parts Manual: Chelsea 210 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
