The Chelsea 249FMLLX-B209 or 249FMLLXB209 is a hydraulic PowerShift PTO assembly engineered for Ford transmissions with a Ford 6-bolt mounting configuration. It delivers 56+ HP (41-50 kW) output and is rated for intermittent torque up to 200 lb-ft (271 Nm), check the Chelsea application pages for your specific torque ratings. The output shaft is a 1-1/4" round. A built-in noise suppression system makes this the only quiet PTO designed for the Ford Super Duty TorqueShift 6. A single-hose connection with an integrated actuation valve simplifies installation, reduces leak paths, and eliminates the need for special installation tools. A genuine Chelsea part sold by Pro Gear and Transmission. Call us to confirm proper fit for your application.
Features
Ford 6-bolt mounting configuration
Hydraulic PowerShift (hydraulic) shift type
1-1/4" round output shaft
56+ HP (41-50 kW) output power; 57 HP at 1,488 RPM
Intermittent torque rating up to 200 lb-ft (271 Nm), verify against Chelsea application pages
Noise suppression system, designed as the only quiet PTO for the Ford Super Duty TorqueShift 6
Single-hose connection with integrated actuation valve reduces installation time and eliminates extra leak paths
No special installation tools required
Tech Specs
- Transmission Manufacturer: Ford
- Mounting Type: Ford 6-Bolt
- Shift Type: Hydraulic PowerShift
- Output Shaft Type: 1-1/4" Round
- Output Power: 56+ HP (41-50 kW)
- Shaft Power: 57 HP (42 kW) at 1,488 RPM
- Intermittent Torque: Up to 200 lb-ft (271 Nm), check Chelsea application pages for actual torque ratings
