The Chelsea 272GCHVP-15RK is a 272 Series 6-bolt hot shift power take-off assembly designed for medium-duty truck applications including aerial, construction equipment, towing and recovery, and water trucks. The 272 Series consolidates earlier Chelsea PTO lines into one platform and supports up to 300 lb-ft intermittent torque. This series is available with hydraulic or pneumatic shift and includes an integral air control valve. Rotatable flanges give installation flexibility, and the wet-spline option is available for extended PTO and pump shaft service life. Also referenced as 272GCHVP15RK. Call us to confirm proper fit for your application.
Features
Chelsea 272 Series 6-bolt hot shift PTO assembly
Intermittent torque rating: 201-300 lb-ft (401-500 Nm)
Hydraulic or pneumatic shift with integral air control valve
Rotatable flanges for flexible installation
Wet-spline option supports extended PTO and pump shaft life
Smart-Start option available for high-torque start-up conditions
Tech Specs
- Mounting Type: 6-Bolt
- Shift Type: Hot Shift - Hydraulic or Pneumatic (Air)
- Intermittent Torque: 201-300 lb-ft (401-500 Nm)
- Output Power: 56+ HP (41-50 kW)
- Integral Air Control Valve: Yes
- Wet-Spline Option: Available
- Smart-Start Option: Available for high-torque start-up
Additional Information
The Chelsea 272 Series consolidates several earlier Chelsea medium-duty PTO lines - including the 230, 231, 236, 238, 270, and 271 series - into a single updated platform. The series offers nine speed ratios, eighteen shift options, and a range of direct-mount and driveshaft output configurations. Direct-mount outputs include an optional wet-spline design for longer service life on PTO and pump shafts. Driveshaft outputs include the Smart-Start feature for high-torque engagement conditions. Typical markets served include aerial equipment, construction equipment, towing and recovery, water trucks, material handling, and defense applications.Parts Manual: Chelsea 272 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
