The Chelsea 442 Series Power Take-Off, part number 442KLEVX-A4XD or 442KLEVXA4XD, is a 6-bolt transmission-mount PTO built for light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. This unit carries a 0.391:1 gear ratio, air shift actuation, and a 1-1/4" round standard output shaft. Mounting is via standard mount with metric studs. The cast iron housing and tapered cone bearings on the output shaft deliver the series-characteristic torque capacity and long service life. No pressure lube is required for this configuration. Pro Gear and Transmission stocks Chelsea PTO assemblies for the exact spec your application demands. Call us to confirm proper fit for your truck and transmission.
Features
Chelsea 442 Series, 6-bolt transmission mount with metric studs
Gear ratio: 0.391:1
Shift type: Air shift
Output: 1-1/4" round standard shaft
Cast iron housing with tapered cone bearings on the output shaft
Greaseable output shafts; rotatable output flanges for improved clearance
No pressure lube required
Tech Specs
- Product Series: 442
- Input Gear Designator: AH
- Gear Ratio: 0.391:1
- Mounting Option: Standard Mount with Metric Studs
- Shift Type: Air Shift
- Output Option: 1-1/4" Round Standard Shaft
- Assembly: 3
- Lubricant: No Pressure Lube
- Mounting: 6-Bolt
Additional Information
Parts Manual: Chelsea 442 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
