The Chelsea 442 Series Power Take-Off, part number 442GQLQP-D3XK or 442GQLQPD3XK, is a 6-bolt mount PTO configured with 12V electric/air shift actuation. The output is an SAE B 2 or 4-bolt flange with a 7/8" 13-tooth SAE B shaft and a pressure lube requirement. Mounting uses a standard configuration with metric studs. The cast iron housing pairs with tapered cone bearings on the output shaft for long service life in light-to-medium duty vocational applications including dump trucks, tow trucks, and service trucks. The 442 Series accommodates a wide range of 6-bolt transmission applications. Call us to confirm proper fitment for your transmission and truck configuration.
Features
Shift type: Eaton Procision 12V electric/air shift
Output: SAE B 2 or 4-bolt flange with a 7/8" 13-tooth SAE B shaft
Mounting: Standard 6-bolt with metric studs
Lubricant: Pressure lube
Cast iron housing with tapered cone bearings on output shaft
Tech Specs
- Product Series: 442
- Mounting Option: Standard Mount with Metric Studs (G)
- Gear Ratio Code: Q (19/24)
- Input Gear Designator: LQ
- Lube Option: Pressure Lube (P)
- Shift Option: Eaton Procision 12V DC Electric/Air Shift (D)
- Assembly Arrangement: 3
- Output Option: SAE B 2 or 4-Bolt Flange, SAE B Shaft (7/8" 13T) (XK)
Additional Information
Parts manual and diagrams: Chelsea 442 Series PTO parts list with prices
