Chelsea PTO 290 Series Parts Manual
Model Number Designation
| Item | Part No. | Description | Qty | Notes | Price |
|---|
Power Take-Off Bill of Materials 290 Series
Item 35Item 29Item 7Item 9Item 10Item 12Item 10Item 25Item 20Item 21Item 24Item 19Item 27Item 26Item 23Item 26Item 27Item 23Item 35Item 17Item 1Item 10Item 10Item 8Item 7Item 6Item 32Item 31Item 4Item 29Item 18Item 2Item 3Item 13Item 22Item 15Item 15Item 16Item 4Item 5Item 30Click a number on the diagram to highlight that part below.
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| 1 | 1P519X | Housing Standard (includes Item 17) , | 1 | $1,690.76 | Add to Cart | |
| 2 | 3P202 | Output Shaft, Standard (“xd”) | 1 or | $95.42 | Add to Cart | |
| 3 | 550397 | Bearing Cone | 1 | $36.75 | Add to Cart | |
| 4 | 378391 | Retaining Ring | 2 | $2.47 | Add to Cart | |
| 5 | 2P770 | Gear, Output “f” Ratio (37 Teeth) | 1 or | $261.26 | Add to Cart | |
| 2P771 | Gear, Output “l” Ratio (34 Teeth) | 1 | $257.48 | Add to Cart | ||
| 2P697 | Gear, Output “q” Ratio (24 Teeth) | 1 | $238.13 | Add to Cart | ||
| 2P699 | Gear, Output “u” Ratio (20 Teeth) | 1 | $259.97 | Add to Cart | ||
| 6 | 550532 | Bearing Cone | 1 | $36.75 | Add to Cart | |
| 7 | 22P241 | Gasket, Bearing Cap .010" Thick | A.R. | $2.30 | Add to Cart | |
| 22P242 | Gasket, Bearing Cap .020" Thick | A.R. | $10.49 | Add to Cart | ||
| 22P243 | Gasket, Bearing Cap .015" Thick | A.R. | $10.49 | Add to Cart | ||
| 8 | 328274X | Bearing Cap Assembly, Closed End | 1 | $64.09 | Add to Cart | |
| 9 | 328273X | Bearing Cap Assembly, Open End | 1 | $64.09 | Add to Cart | |
| 10 | 37843010 | Capscrew, Hex Head (.312" 18 X 1 .0") | 8 | $1.76 | Add to Cart | |
| 12 | 28P216 | Oil Seal Standard Output , | 1 | $21.40 | Add to Cart | |
| 13 | 50000729 | Woodruff Key, “xd” Output | 1 | $3.11 | Add to Cart | |
| 15 | 550439 | Bearing Cone | 2 | $51.63 | Add to Cart | |
| 16 | 14P15 | Spacer, Idler Gear | A.R. | $5.70 | Add to Cart | |
| 17 | 50059716 | Pin, Slotted | 1 | $1.18 | Add to Cart | |
| 18 | 9P81 | Shaft, Idler | 1 | $206.98 | Add to Cart | |
| 329363X | Air Shift Control Assembly (includes Items 19-28) | $337.38 | Add to Cart | |||
| 19 | 34P130 | Cover, Shift | 1 | $95.72 | Add to Cart | |
| 20 | 32P180 | Shifter Fork | 1 | $105.58 | Add to Cart | |
| 21 | 11P75 | Shaft, Shifter | 1 | $60.75 | Add to Cart | |
| 22 | 3784474 | Capscrew, Allen Head | 1 | $1.78 | Add to Cart | |
| 23 | 28P42 | Oil Ring | 2 | $3.59 | Add to Cart | |
| 24 | 28P41 | Oil Ring | 1 | $5.03 | Add to Cart | |
| 25 | 37P21 | Spring, Shifter | 1 | $2.86 | Add to Cart | |
| 26 | 378315 | Cover Plug | 2 | $5.55 | Add to Cart | |
| 27 | 378316 | Snap Ring | 2 | $1.68 | Add to Cart | |
| 28 | 379639 | Indicator Switch | 1 | $25.03 | Add to Cart | |
| 29 | 35P8 | Gasket, Shift Cover (all Except “f” Ratio) | 2 or | $3.48 | Add to Cart | |
| 35P8 | Gasket, Shift Cover (“f” Ratio Only) | 3 | $3.48 | Add to Cart | ||
| 30 | 5A125 | Spacer, (all Except “f” Ratio) | 1 or | $137.79 | Add to Cart | |
| 5A125 | Spacer, (“f” Ratio Only) | 1 | $137.79 | Add to Cart | ||
| 5A250 | Spacer, (“f” Ratio Only) | 1 | $138.39 | Add to Cart | ||
| 31 | 68P2 | Name Plate | 1 | $2.65 | Add to Cart | |
| 32 | 378422 | Drive Screw | 2 | $11.52 | Add to Cart | |
| 35 | 37843010 | Capscrew, Hex Head (.312"-18 X 1 .000") All Except “f” Ratio | 4 or | $1.76 | Add to Cart | |
| 37843012 | Capscrew, Hex Head (.312"-18 X 1 .250") “f” Ratio Only Parts Shipped Loose | 4 | $1.83 | Add to Cart | ||
| 32817076X | Stud Kit, Standard | 1 | $30.69 | Add to Cart | ||
| 717072X | Stud Kit, Metric | 1 | $53.10 | Add to Cart | ||
| 3289486X | Gasket & Installation Instructions | 1 | $24.01 | Add to Cart | ||
| 378414 | Pressure Protection Valve (“v” Shifter Only) | 1 | $66.97 | Add to Cart | ||
| 379640 | Booted Connector (“v” Shifter Only) | $18.40 | Add to Cart | |||
| 32838837X | Installation Kit, Air Shift, “a” Shifter | 1 | $367.41 | Add to Cart | ||
| 32838847X | Installation Kit, Air Shift, “p” Shifter | 1 | $563.43 | Add to Cart | ||
| 32838848X | Installation Kit, Air Shift, “q” Shifter | 1 | $544.19 | Add to Cart | ||
| 32838865X | Installation Kit, Air Shift, “s” Shifter | 1 | $762.60 | Add to Cart | ||
| 32916612X | Installation Kit, E-z Shift, “z” Shifter | 1 | Call for availability | |||
| 328751X | Installation Kit, “y” Shifter Service Kits | 1 | $65.59 | Superseded by 3287511XAdd to Cart | ||
| 32835650X | Gasket And Seal Kit | $50.49 | Add to Cart | |||
| 32835671X | Gasket And Seal Kit, Air Shift | $63.15 | Add to Cart | |||
| 328390123X | Air Shift Field Conversion Kit ( Wire To Air) | 1 | $359.12 | Add to Cart |
Power Take-Off Air Shift Parts 290 Series
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| 329363X | Shifter Cover Assembly, Air Shift ( Includes Items 48-57) | 1 | $337.38 | Add to Cart | ||
| 48 | 34P130 | Shifter Cover | 1 | $95.72 | Add to Cart | |
| 49 | 378316 | Snap Ring | 2 | $1.68 | Add to Cart | |
| 50 | 378315 | Cover Plug | 2 | $5.55 | Add to Cart | |
| 51 | 28P42 | O-ring | 2 | $3.59 | Add to Cart | |
| 52 | 37P21 | Shifter Spring | 1 | $2.86 | Add to Cart | |
| 53 | 11P75 | Shaft, Shifter | 1 | $60.75 | Add to Cart | |
| 54 | 28P41 | O-ring | 1 | $5.03 | Add to Cart | |
| 55 | 32P180 | Shifter Fork | 1 | $105.58 | Add to Cart | |
| 56 | 3784474 | Capscrew, Socket Head W/ Lockpatch (.312"-18 X .750") | 1 | $1.78 | Add to Cart | |
| 57 | 379639 | Indicator Switch (normally Off) | 1 | $25.03 | Add to Cart | |
| 58 | 379904 | Push Connect, For 1/4" Tubing | 1 | $7.13 | Add to Cart | |
| 59 | 35P8 | Gasket, Shifter Cover | 1 | $3.48 | Add to Cart | |
| 60 | 37843010 | Capscrew, Hex Head (.312"-18 X 1 .000") | 4 | $1.76 | Add to Cart | |
| 37843012 | Capscrew, Hex Head ( .312"-18 X 1 .250") “f” Ratio Only Air Shift Conversion Kits | 4 | $1.83 | Add to Cart | ||
| 328390105X | Lever To Air 12V | 1 | Call for availability | |||
| 328390106X | Lever To Air 24V | 1 | Call for availability | |||
| 328390117X | Lever Or Cable To Air | 1 | $576.15 | Add to Cart | ||
| 328390119X | Lever Or Cable To Electric/air, 12V | 1 | $1,071.10 | Add to Cart | ||
| 328390120X | Lever Or Cable To Electric/air, 24V 3 Chelsea Products , Ms | 1 | $708.43 | Add to Cart |
Model Number Designation 290 Series Input Gear Chart
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| F2937 | Ra Rotatable S.a.e. = | “B” 2 Bolt | Call for availability | |||
| L3134 | Rb Rotatable S.a.e. = | “B” 4 Bolt | Call for availability | |||
| Q2934 | Rc Rotatable S.a.e. = | “A” 2 Bolt | Call for availability | |||
| 290QGE | 5-P-992 32 29 Eaton | 4106 A & B | Call for availability | |||
| 290QGF | 5-P-993 26 29 | Eaton 4106 OD | Call for availability | |||
| 290UGE | 5-P-1136 32 29 Eaton | 4106 A & B | Call for availability | |||
| 290FHU | 5-P-1221 26 29 | Mack T2060A | Call for availability | |||
| 290LHU | 5-P-1222 26 31 | Mack T2060A | Call for availability | |||
| 290QHU | 5-P-1223 26 29 | Mack T2060A | Call for availability | |||
| 290UHU | 5-P-1224 26 29 | Mack T2060A | Call for availability | |||
| 290FHZ | 5-P-1238 34 29 CL-3905/FSO-4305 | Call for availability | ||||
| 290LHZ | 5-P-1239 34 31 CL-3905/FSO-4305 | Call for availability | ||||
| 290QHZ | 5-P-1240 34 29 CL-3905/FSO-4305 | Call for availability | ||||
| 290UHZ | 5-P-1241 34 29 CL-3905-FSO-4305 | Call for availability |
Output Options Bills of Materials 290 Series
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| 3P862 | Output Shaft | 1 | Call for availability | |||
| 28P216 | Oil Seal | 1 | $21.40 | Add to Cart | ||
| 239102X | Bearing Cap Assy.(21 -P-532) | 1 | Call for availability | |||
| 3784478 | Socket Head Capscrew (.312" 18 X 1 .5") | 4 | $2.32 | Add to Cart | ||
| 3P854 | Output Shaft | 1 | $599.82 | Add to Cart | ||
| 28P219 | Oil Seal | 1 | $28.20 | Add to Cart | ||
| 329088X | Bearing Cap Assy.(21 -P-522) | 1 | $363.17 | Add to Cart | ||
| 37844710 | Socket Head Capscrew (.312" 18 X 1 .5") | 4 | $4.45 | Add to Cart | ||
| 3P282 | Output Shaft | 1 | $187.84 | Superseded by 3P282XAdd to Cart | ||
| 328989X | Bearing Cap Assy.(21 -P-472) | 1 | $378.21 | Add to Cart | ||
| 3P844 | Output Shaft | 1 | $750.67 | Add to Cart | ||
| 28P230 | Oil Seal | 1 | Call for availability | |||
| 329052X | Bearing Cap Assy.(21 -P-508) | 1 | $613.82 | Add to Cart | ||
| 379982 | Hex Washer Flange Bolt (.312" 18 X 2 .5") | 4 | Call for availability | |||
| 3P851 | Output Shaft | 1 | Call for availability | |||
| 3P938X | “gm” | 1 or | $819.60 | Add to Cart | ||
| 3P941X | “gh”, “gj” Shaft Assemblies | 1 | $1,076.84 | Add to Cart | ||
| 5001682 | Lube Fitting (zerk) | 1 | $6.59 | Add to Cart | ||
| 379819 | Grease Fitting Cap | 1 | $2.07 | Add to Cart | ||
| 379688 | Coupling Lube Pack (5/8 Fl .oz) | 1 | $8.98 | Add to Cart | ||
| 28P268 | Rear Bearing Cap Shaft Oil Seal | 1 | $69.47 | Add to Cart | ||
| 328273X | Rear Bearing Cap Assembly | 1 | $64.09 | Add to Cart | ||
| 37843010 | Rear Bearing Cap Hex Head Capscrew | 4 | $1.76 | Add to Cart | ||
| 3P768 | Output Shaft | 1 | $728.64 | Superseded by 3P768XAdd to Cart | ||
| 28P275 | Oil Seal | 1 | $37.46 | Add to Cart | ||
| 329412X | Bearing Cap Assy. (21 -P-675) | 1 | Call for availability | |||
| 3784476 | Socket Head Capscrew (.312" 18 X 1 .0") Continued 5 Chelsea Products , Ms | 4 | $4.33 | Add to Cart | ||
| RA3P283 | Output Shaft | 1 | Call for availability | |||
| 329195X | Bearing Cap Assy. (21 -P-574) -P-628 Pump Flange (ship Loose With Unit) | 1 | $132.25 | Add to Cart | ||
| 328170207X | Capscrew Bag Kit 378170-6 Socket Head Capscrew | 1 | $9.52 | Add to Cart | ||
| RB3P283 | Output Shaft | 1 | Call for availability | |||
| RC3P800 | Output Shaft | 1 | Call for availability | |||
| 329322X | Bearing Cap Assy (21 -P-640) -P-638 Pump Flange | 1 | $744.53 | Add to Cart | ||
| 328170210X | Capscrew Bag Kit 378447-4 Socket Head Capscrew (.312" 18 X .75") | 1 | $47.78 | Add to Cart | ||
| RE3P924 | Output Shaft | 1 | Call for availability | |||
| 329264X | Bearing Cap Assy. (21 -P-629) -P-654 Pump Flange | 1 | $164.26 | Add to Cart | ||
| 28P271 | O-ring | 1 | $28.61 | Add to Cart | ||
| RF3P924 | Output Shaft | 1 | Call for availability | |||
| XG3P281 | Output Shaft | 1 | Call for availability | |||
| 328580X | Bearing Cap Assy. (21 -P-259) | 1 | $439.30 | Add to Cart | ||
| XJ3P284 | Output Shaft | 1 | Call for availability | |||
| XK3P282 | Output Shaft | 1 | Call for availability | |||
| 328333X | Bearing Cap Assy.(21 -P-424) | 1 | $239.73 | Add to Cart | ||
| XL3P283 | Output Shaft | 1 | Call for availability | |||
| 3P283 | Output Shaft | 1 | $187.84 | Add to Cart | ||
| 329194X | Bearing Cap Assembly (21 -P-574) | 1 | $135.04 | Add to Cart | ||
| 379673 | Hex Shoulder Screw (.312" 24) | 4 | $12.77 | Add to Cart | ||
| 379063 | Flat Washer | 4 | $2.70 | Add to Cart | ||
| 328711X | Pump Mounting Kit | 1 | $14.26 | Add to Cart | ||
| 378919 | Washer | 4 | $1.97 | Add to Cart | ||
| 5009631 | Hex Lock Nut (.312" 24) | 4 | No longer available - Call for replacement | |||
| 3P766 | Output Shaft | 1 | $787.30 | Add to Cart | ||
| 329273X | Bearing Cap Assy. For 660 & 680 Series | 1 or | $287.83 | Add to Cart | ||
| 379111 | Square Key | 1 | $23.18 | Add to Cart | ||
| 501181 | Hex Locknut (1 .0" 20) | 1 | No longer available - Call for replacement | |||
| 328234X | Bearing Cap Assy. (21 -P-614) | 1 | Call for availability |
Direct Mount Pump Conversion Kits 290 Series Bills of Materials for Pump Flange Conversion Kits
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| 328591 | -10X Conversion Kit (xd Xg) - | $1,002.00 | Add to Cart | |||
| 22P241 | Gasket, Bearing Cap .010" Thick | 2 | $2.30 | Add to Cart | ||
| 22P242 | Gasket, Bearing Cap .020" Thick | 2 | $10.49 | Add to Cart | ||
| 22P243 | Gasket, Bearing Cap .015" Thick | 1 | $10.49 | Add to Cart | ||
| 28P216 | Oil Seal | 1 | $21.40 | Add to Cart | ||
| 3P281 | Output Shaft | 1 | $224.42 | Add to Cart | ||
| 328580X | Bearing Cap Assy.(21 -P-259) | 1 | $439.30 | Add to Cart | ||
| 378391 | Retaining Ring | 2 | $2.47 | Add to Cart | ||
| 3784478 | Socket Head Capscrew ( .312" 18 X 1 .5") | 4 | $2.32 | Add to Cart | ||
| 3P284 | Output Shaft | 1 | $289.72 | Add to Cart | ||
| 3P282 | Output Shaft | 1 | $187.84 | Superseded by 3P282XAdd to Cart | ||
| 328333X | Bearing Cap Assy.(21 -P-424) | 1 | $239.73 | Add to Cart | ||
| 379688 | Grease Pack 8 Chelsea Products | 1 | $8.98 | Add to Cart |
Pump Flange Conv. Kits Bills of Materials 290 Series
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| 32859116X | Conversion Kit (xd Xl) - | $357.11 | Add to Cart | |||
| 22P241 | Gasket, Bearing Cap .010" Thick | 2 | $2.30 | Add to Cart | ||
| 22P242 | Gasket, Bearing Cap .020" Thick | 2 | $10.49 | Add to Cart | ||
| 22P243 | Gasket, Bearing Cap .015" Thick | 1 | $10.49 | Add to Cart | ||
| 28P216 | Oil Seal | 1 | $21.40 | Add to Cart | ||
| 3P283 | Output Shaft | 1 | $187.84 | Add to Cart | ||
| 328580X | Bearing Cap Assy.(21 -P-259) | 1 | $439.30 | Add to Cart | ||
| 378391 | Retaining Ring | 2 | $2.47 | Add to Cart | ||
| 3784478 | Socket Head Capscrew ( .312" 18 X 1 .5") | 4 | $2.32 | Add to Cart | ||
| 379688 | Grease Pack | 1 | $8.98 | Add to Cart | ||
| 32859128X | Conversion Kit (xd Ak) - | $392.52 | Add to Cart | |||
| 3P282 | Output Shaft | 1 | $187.84 | Superseded by 3P282XAdd to Cart | ||
| 328989X | Bearing Cap Assy.(21 -P-472) | 1 | $378.21 | Add to Cart | ||
| 32859129X | Conversion Kit (xd Ff) - | No longer available - Call for replacement | ||||
| 28P219 | Oil Seal | 1 | $28.20 | Add to Cart | ||
| 3P851 | Output Shaft | 1 | Call for availability | |||
| 329088X | Bearing Cap Assy.(21 -P-522) | 1 | $363.17 | Add to Cart | ||
| 37844710 | Socket Head Capscrew ( .312" 18 X 2 .0") | 4 | $4.45 | Add to Cart | ||
| 32859152X | Conversion Kit (xd Xr) - | $260.80 | Add to Cart | |||
| 328711X | Pump Mounting | 1 | $14.26 | Add to Cart | ||
| 378919 | Washer (.328" Id X .062") | 4 | $1.97 | Add to Cart | ||
| 5009631 | Hex Lock Nut ( .312"-24) | 4 | No longer available - Call for replacement | |||
| 329194X | Bearing Cap Assy.(21 -P-574) | 1 | $135.04 | Add to Cart | ||
| 379637 | Socket Head Screw ( .312" 18) | 2 | $1.69 | Add to Cart | ||
| 379063 | Flat Washer (.339" Id X .052") | 4 | $2.70 | Add to Cart | ||
| 379673 | Stud Shoulder (.312"-18 X .312"-24) , | 4 | $12.77 | Add to Cart | ||
| 32859155X | Conversion Kit (xd Ra) - | $382.35 | Add to Cart | |||
| 21P628 | Pump Flange | 1 | $100.24 | Add to Cart | ||
| 329195X | Bearing Cap Assy.(21 -P-574) | 1 | $132.25 | Add to Cart | ||
| 3784476 | Socket Head Capscrew ( .312" 18 X 1 .0") | 7 | $4.33 | Add to Cart | ||
| 328591 | -56X Conversion Kit (xd Rb) - | $1,002.00 | Add to Cart | |||
| 21P572 | Pump Flange | 1 | $114.69 | Add to Cart | ||
| 37844711 | Socket Head Capscrew ( .312" 18 X 2 .250") | 4 | $7.47 | Add to Cart | ||
| 3P844 | Output Shaft | 1 | $750.67 | Add to Cart | ||
| 28P230 | Oil Seal | 1 | Call for availability | |||
| 329052X | Bearing Cap Assy.(21 -P-508) | 1 | $613.82 | Add to Cart | ||
| 21P626 | Pump Flange | 1 | $115.30 | Add to Cart | ||
| 3P924 | Output Shaft | 1 | $733.31 | Add to Cart | ||
| 329264X | Bearing Cap Assy.(21 -P-629) | 1 | $164.26 | Add to Cart | ||
| 28P638 | O-ring | 1 | Call for availability | |||
| 21P638 | Pump Flange | 1 | $643.81 | Add to Cart | ||
| 3P800 | Output Shaft | 1 | $319.56 | Add to Cart | ||
| 329322X | Bearing Cap Assy.(21 -P-640) | 1 | $744.53 | Add to Cart | ||
| 3784464 | Screw, Socket ( .250" 20 X .750") 10 Chelsea Products | 6 | $5.98 | Add to Cart | ||
| 328591116X | Conversion Kit (xd Gh) - | $864.02 | Add to Cart | |||
| 3P941X | Output Shaft | 1 | $1,076.84 | Add to Cart | ||
| 379819 | Grease Fitting Cap | 1 | $2.07 | Add to Cart | ||
| 5001682 | Fitting | 1 | $6.59 | Add to Cart | ||
| 328273X | Closed Bearing Cap Assy.(21 -P-418) | 1 | $64.09 | Add to Cart | ||
| 28P268 | Oil Seal | 1 | $69.47 | Add to Cart | ||
| 28P271 | O-ring | 1 | $28.61 | Add to Cart | ||
| 328591122X | Conversion Kit (xd Xx) - | $639.97 | Add to Cart | |||
| 501181 | Hex Nut | 1 | No longer available - Call for replacement | |||
| 3P766 | Output Shaft | 1 | $787.30 | Add to Cart | ||
| 37843010 | Hex Capscrew ( .312" 18 X 1 .0") | 4 | $1.76 | Add to Cart | ||
| 379111 | Square Key | 1 | $23.18 | Add to Cart | ||
| 328591134X | Conversion Kit (xd Re) - | $583.72 | Add to Cart | |||
| 21P654 | Pump Flange | 1 | $88.51 | Add to Cart | ||
| 328591138X | Conversion Kit (xd Gj) - | $864.02 | Add to Cart | |||
| 3P768 | Output Shaft | 1 | $728.64 | Superseded by 3P768XAdd to Cart | ||
| 28P275 | Oil Seal | 1 | $37.46 | Add to Cart | ||
| 329412X | Bearing Cap Assy. (21 -P-675) | 1 | Call for availability | |||
| 3P938X | Output Shaft | 1 | $819.60 | Add to Cart |
Pump Flange & Shaft Dimensions 290 Series
| Item | Part No. | Description | Qty | Notes | Price |
|---|
Additional Parts Listed in This Manual
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| 378170-6 | Socket Head Capscrew | 3 | Call for availability | |||
| 328591-10X | Conversion Kit (xd Xg) | $174.50 | Add to Cart | |||
| 328591-11X | Conversion Kit (xd Xj) | $369.75 | Add to Cart | |||
| 328591-56X | Conversion Kit (xd Rb) | $382.35 | Add to Cart | |||
| 328591-70X | Conversion Kit (xd Az) | $903.54 | Add to Cart | |||
| 328591-78X | Conversion Kit (xd Rf) | $586.51 | Add to Cart | |||
| 328591-112X | Conversion Kit (xd Rc) | Call for availability | ||||
| 328591-146X | Conversion Kit (xd My) | Call for availability | ||||
| 328591-148X | Conversion Kit (xd Gm) | Call for availability |
This is the complete factory parts breakdown for the Chelsea PTO 290, with every part in the manual matched to our live inventory. We stock 178 of the 230 parts above; click any part number to view it, or add it straight to your cart. Click a number on any diagram to jump to that part.
No parts match that search. Try the part number with no dashes.
