The Chelsea 378414 is a Pressure Protection Valve designed for air-shift PTO systems, where it regulates line pressure to protect the pneumatic shift circuit. Listed as item 49 in the Chelsea 540 Series PTO illustrated parts manual, this valve is a direct-fit service component for that platform. Cross-references include 118181, 1450-378414, 9054107, KN31000, HM1PPV, S-C088 or SC088, CHE-378414, and WA9054107, making it straightforward to match against existing purchase records or competing part numbers. Sold by Pro Gear and Transmission. Call us to confirm proper fit for your PTO application.
Features
Pressure Protection Valve for air-shift PTO systems
Regulates PTO line pressure in the pneumatic shift circuit
Listed as item 49 in the Chelsea 540 Series PTO illustrated parts manual
Dimensions: 3 in. H x 2.25 in. W x 2.25 in. L
Cross-references: 118181, 1450-378414, 9054107, KN31000, HM1PPV, S-C088, CHE-378414, WA9054107
Genuine Chelsea component sold by Pro Gear and Transmission
Tech Specs
- Part Number: 378414
- Part Type: Pressure Protection Valve
- Application: Air-Shift PTO Systems
- Series Reference: Chelsea 540 Series PTO (item 49 in illustrated parts manual)
- Dimensions (H x W x L): 3 in. x 2.25 in. x 2.25 in.
- Cross-References: 118181, 1450-378414, 1450378414, 9054107, KN31000, HM1PPV, S-C088, SC088, CHE-378414, CHE378414, WA9054107
