The Chelsea 880 Series Power Take-Off Assembly, part number 880XMAHX-M5XY or 880XMAHXM5XY, is an 8-bolt, lever mechanical shift PTO built for heavy-duty applications including fire trucks, bulk haulers, oil field equipment, aerial units, and large recovery trucks. Output is through a 1-1/2"-10 spline shaft with a 1410 companion flange. Intermittent torque rating for the 880 Series reaches 500 lb-ft (678 Nm); check application pages for your specific rating. Shaft power output is 48 HP at 500 RPM and 95 HP at 1000 RPM. The cast iron housing and tapered cone bearings handle demanding, high-torque duty cycles. Compatible with Volvo/Mack, Allison, Eaton/Fuller, and other manual transmissions using an 8-bolt aperture. Call us to confirm proper fit for your transmission.
Features
8-bolt mounting fits most manual transmissions with an 8-bolt aperture, including Volvo/Mack, Allison, and Eaton/Fuller
Lever mechanical shift with optional air control shift available
1-1/2"-10 spline output shaft with 1410 series companion flange
Intermittent torque rating up to 500 lb-ft (678 Nm) for the 880 Series - confirm application-specific rating before ordering
Shaft power: 48 HP (36 kW) at 500 RPM; 95 HP (71 kW) at 1000 RPM
Cast iron housing with removable shift cover for straightforward backlash adjustment; dual-pump output allows mounting a pump on each end
Tech Specs
- Intermittent Torque: 500 lb-ft (678 Nm) - Check Application Pages for Actual Torque Rating
- Transmission Compatibility: Volvo/Mack, Allison, Eaton/Fuller, Other
- Shift Type: Lever Mechanical
- Mounting Type: 8-Bolt
- Output Shaft Type: 1-1/2" - 10T Spline with 1410 Series Companion Flange
- Output Power: 56+ HP (51+ kW)
- Shaft Power: 48 HP (36 kW) at 500 RPM; 95 HP (71 kW) at 1000 RPM
Additional Information
Parts Manual: Chelsea 880 Series PTO Parts Manual (PDF) — exploded views, item numbers and the full parts breakdown for this series.
