Meritor MTC-4210XLEV Transfer Case Parts Manual
MTC4210XLEV Yokes
Click a number on the diagram to highlight that part below.
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| 17TYS3876 | $330.87 | Add to Cart | ||||
| 17NYS3861 | $868.09 | Add to Cart | ||||
| 176TYS3827 | — | Call for availability | ||||
| 176NYS3814 | $518.13 | Add to Cart | ||||
| 140TYS38 | — | Call for availability | ||||
| A11205X2728 | $104.91 | Add to Cart | ||||
| ANDREAROUTPUTR945007 | — | Call for availability | ||||
| OUTPUTR945007 | — | Call for availability | ||||
| R945007 | $108.48 | Add to Cart |
MTC4210XLEV
Click a number on the diagram to highlight that part below.
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| 1 | 3266Z1534 | Pump Cover | 1 | $257.46 | Add to Cart | |
| 1 | 5X1348 | O-ring (pump Cover) | 1 | $12.10 | Add to Cart | |
| 2 | 40X1233 | Lock Nut, Fin | 4 | M45 1 .5 thd.; x | $17.72 | Add to Cart |
| 3 | 1229N1730 | Flat Washer | 4 | 1 .79" ID 3.00" OD 0.19" wide; x x | $52.70 | Add to Cart |
| 4 | A11205R2592 | Seal Assembly (front And Rear Output) | 2 | 3.25" ID 4.25" OD 0.86" long; x x | — | Call for availability |
| 5 | 40X1341 | Lock Nut, Fin | 1 | 2.25"-12 thd. | $149.13 | Add to Cart |
| 6 | 1229E4113 | Washer | 1 | 2.28" ID 3.25" OD 0.32" wide; x x | $360.25 | Add to Cart |
| 7 | 3289L1182 | Rear Transfer Case Cover | 1 | $2,100.56 | Add to Cart | |
| 8 | 1779F344 | Shipping Plug | 3 | $16.10 | Add to Cart | |
| 9 | 3261A1067 | Shift Cylinder | 2 | $24.14 | Add to Cart | |
| 10 | 5X1326 | O-ring | 2 | 1 .459" ID 0.208" thick; x | $17.60 | Add to Cart |
| 11 | 2230Q1369 | Piston (outer) | 1 | $188.24 | Add to Cart | |
| 12 | 5X1290 | O-ring (inner) | 2 | 0.734" ID 0.139" thick; x | $4.42 | Add to Cart |
| 13 | A1199C1043 | Breather Assembly | 1 | $127.20 | Add to Cart | |
| 14 | S2442 | Capscrew (speed Sensor Retainer) | 1 | $6.64 | Add to Cart | |
| 15 | A1199R4048 | Breather Assembly | 1 | $133.60 | Add to Cart | |
| 16 | HM813810 | Bearing Cup | 3 | 5.00" OD; cup | $46.33 | Add to Cart |
| 17 | HM212011 | Bearing Cup | 3 | 4.8125" OD; cup | $21.22 | Add to Cart |
| 18 | HM212049 | Bearing Cone | 3 | 2.625" ID cone | $37.35 | Add to Cart |
| 19 | 2297K6771 | Magnet | 3 | $34.20 | Add to Cart | |
| 20 | S2714A2 | Bolt/capscrew | 29 | 7/16"-14 thd 1 .75"; x | $742.20 | Add to Cart |
| 20 | 1229E1513 | Flat Washer | 37 | 0.47" ID 0.81" OD 0.09" wide; x x | $174.00 | Add to Cart |
| 21 | S2710A2 | Bolt/capscrew | 8 | $53.80 | Add to Cart | |
| 22 | HM813843 | Bearing Cone | 3 | 2.4375" ID cone | $117.23 | Add to Cart |
| 23 | 3892L5862 | Front Output Gear | 1 | $1,691.73 | Add to Cart | |
| 24 | 3892X6316 | Idler Gear | 1 | $1,697.71 | Add to Cart | |
| 25 | 3297G1567 | Output Shaft | 1 | $1,342.84 | Add to Cart | |
| 26 | 2258U411 | Spring | 1 | $211.00 | Add to Cart | |
| 27 | 3296T1346 | Shift Fork | 1 | $91.82 | Add to Cart | |
| 28 | 2244S1189 | Push Rod (differential Lock Out) | 1 | $155.90 | Add to Cart | |
| 29 | 3107S1397 | Clutch Collar | 1 | $196.30 | Add to Cart | |
| 30 | 1229U4857 | Snap Ring | 2 | 0.689" ID | $72.00 | Add to Cart |
| 31 | 3892H5676 | Rear Output Gear | 1 | $1,559.20 | Add to Cart | |
| 32 | 2230T1346 | Inner Piston | 1 | $219.54 | Add to Cart | |
| 33 | 5X1292 | O-ring | 1 | 1 .17" ID 0.139" thick; x | $20.04 | Add to Cart |
| 34 | 5X1291 | O-ring (housing) | 2 | 0.984" ID 0.139" thick; x | $5.48 | Add to Cart |
| 35 | 2244T1190 | Shifter Shaft | 1 | $221.83 | Add to Cart | |
| 36 | S1712A2 | Bolt/capscrew | 1 | 7/16" 1 .5"; x | $58.87 | Add to Cart |
| 37 | S1612A2 | Bolt/capscrew | 1 | 3/8" 1 .5"; x | $49.73 | Add to Cart |
| 38 | 3296Q1317 | Shift Fork | 1 | $283.12 | Add to Cart | |
| 39 | A1205X2728 | Seal Assembly (input) | 1 | 3.25" ID 4.25" OD 0.58" long; x x | — | Call for availability |
| 39A | A1199U4025 | Yoke Sleeve | 1 | — | Call for availability | |
| 40 | 3297P1810 | Input Shaft | 1 | $974.56 | Add to Cart | |
| 41 | 3892R5660 | Input Gear (high) | 1 | $1,043.53 | Add to Cart | |
| 42 | 3107K1181 | Clutch Collar | 1 | $537.89 | Add to Cart | |
| 43 | 1246T1190 | Dowel | 2 | 0.375" dia 1 .00" long; x | $33.95 | Add to Cart |
| 44 | 1250E473 | Magnet Plug | 2 | 3/4"-14 NPT square socket | $16.72 | Add to Cart |
| 46 | P112 | Fill Plug | 1 | $77.80 | Add to Cart | |
| 47 | S24142 | Bolt/capscrew | 6 | 1/4"-20 thd 1 .75" | $19.48 | Add to Cart |
| 48 | WA34 | Flat Washer | 7 | $49.20 | Add to Cart | |
| 49 | 2230T1190 | Piston | 1 | $97.13 | Add to Cart | |
| 50 | A1228M1807 | Bearing Cone | 2 | $97.59 | Add to Cart | |
| 51 | 1228J1804 | Bearing Cup | 2 | $48.90 | Add to Cart | |
| 52 | S2814A2 | Bolt/capscrew | 7 | 1/2"-13 thd 1 .75"; x | $40.10 | Add to Cart |
| 53 | 1229C1511 | Flat Washer | 7 | 0.53" ID 0.88" OD 0.09" wide; x x | $141.00 | Add to Cart |
| 54 | 3226D1512 | Bearing Cage Assembly | 1 | — | Call for availability | |
| 55 | A2206K1545 | Elbow Assembly | 1 | 3/8"-18 NPT | $113.85 | Add to Cart |
| 56 | 5X1327 | O-ring (bearing Cage) | 1 | 7.483" 0.139" thick; x | $8.03 | Add to Cart |
| 57 | A3303X1038 | Pump Assembly | 1 | $1,216.41 | Add to Cart | |
| 58 | 2206Z1430 | Connector Fitting | 1 | Without Oil Cooler | $22.88 | Add to Cart |
| 59 | A2296V1166 | Tube Assembly | 1 | $72.48 | Add to Cart | |
| 60 | 3155Q1499 | Angle Bracket | 1 | — | Call for availability | |
| 61 | 3266G1567 | Cover | 1 | $211.09 | Add to Cart | |
| 62 | 3290B1276 | Transfer Case (front) | 1 | — | Call for availability | |
| 63 | 1229R5322 | Snap Ring | 1 | $5.81 | Add to Cart | |
| 64 | 3892F6194 | Input Gear (low) | 1 | $536.98 | Add to Cart | |
| 65 | A3380L1858 | Speed Sensor | 1 | $70.84 | Add to Cart | |
| 66 | 2206G1541 | T-fitting | 1 | Cooler Equipped | $24.25 | Add to Cart |
| 66A | 2206C1433 | T-fitting Caps Meritorpartsonline.com | 2 | Cooler Equipped; 5 | — | Call for availability |
| 67 | 1244P2694 | Spacer | 1 | $57.07 | Add to Cart | |
| 68 | 1229H5312 | Thrust Washer | 1 | $373.24 | Add to Cart | |
| 69 | 3237W1167 | Connector Assembly | 1 | — | Call for availability | |
| 69 | 2203K9241 | Shim 0.003" | 1 | $74.20 | Add to Cart | |
| 69 | 2203L9242 | Shim 0.005" | 1 | $82.60 | Add to Cart | |
| 70 | 2203M9243 | Shim 0.010" | 1 | $96.00 | Add to Cart | |
| 70 | 2803F2866 | Shim 0.197" | 1 | — | Call for availability | |
| 70 | 2803P3110 | Shim 0.010" | 2 | $59.20 | Add to Cart | |
| 71 | 2803Q3111 | Shim 0.005" | 2 | Output Bearing Cup | $52.40 | Add to Cart |
| 71 | 2803R3112 | Shim 0.003" | 2 | $58.30 | Add to Cart | |
| 71 | 2803N4252 | Shim 0.010" | 1 | $56.40 | Add to Cart | |
| 72 | 2803P4254 | Shim 0.005" | 1 | Idler Shaft Bearing Cup | $58.50 | Add to Cart |
| 72 | 2803Q4255 | Shim 0.003" | 1 | (Elbow 2206-S-1527 | $55.10 | Add to Cart |
| 73 | A2206S1527 | Filter Assembly Elbow | 1 | Filter 2297-S-3841) | $123.89 | Add to Cart |
| 74 | A2296M1183 | Pump Outlet Tube Assembly | 1 | Without Oil Cooler | $71.61 | Add to Cart |
| 75 | 2206D1434 | Connector Fitting | 1 | $36.56 | Add to Cart | |
| 78 | 2257M1235 | Speed Sensor Clip | 1 | $28.90 | Add to Cart | |
| 79 | 1246S1163 | Pump Drive Pin | 2 | $5.37 | Add to Cart | |
| 80 | A1228K2273 | Needle Bearing | 2 | $56.26 | Add to Cart | |
| 81 | 2 Front Output Yoke | 1 | See table page | — | Call for availability | |
| 82 | 2 Rear Output Yoke | 1 | See table page | — | Call for availability | |
| 83 | 2 Input Yoke | 1 | See table page | — | Call for availability |
Service Kits Seal/Snap Ring Kit 2562
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| R945007 | (front And Rear Output) | 2 | 3.25" ID 4.25" OD 0.86" long; x x | — | Call for availability | |
| A11205X2728 | Seal Assembly (input) | 1 | 3.25" ID 4.25" OD 0.58" long; x x | $104.91 | Add to Cart | |
| 5X1326 | O-ring | 2 | 1 .459" ID 0.208" thick; x | $17.60 | Add to Cart | |
| 5X1290 | O-ring (innver) | 2 | 0.734" ID 0.139" thick; x | $4.42 | Add to Cart | |
| 1229U4857 | Snap Ring | 2 | 0.689" ID | $72.00 | Add to Cart | |
| 5X1292 | O-ring | 1 | 1 .17" ID 0.139" thick; x | $20.04 | Add to Cart | |
| 5X1291 | O-ring (housing) | 2 | 0.984" ID 0.139" thick; x | $5.48 | Add to Cart | |
| 5X1327 | O-ring (bearing Cage) | 1 | 7.483" 0.139" thick; x | $8.03 | Add to Cart | |
| 5X1348 | O-ring (pump Cover) Bearing | 1 | KIT 2889 | $12.10 | Add to Cart | |
| 2203K9241 | Shim 0.003" | 5 | $74.20 | Add to Cart | ||
| 2203L9242 | Shim 0.005" | 5 | Input bearing cage | $82.60 | Add to Cart | |
| 2203M9243 | Shim 0.010" | 5 | $96.00 | Add to Cart | ||
| 2803R3112 | Shim 0.003" | 5 | $58.30 | Add to Cart | ||
| 2803Q3111 | Shim 0.005" | 5 | Housing bearing cups | $52.40 | Add to Cart | |
| 2803P3110 | Shim 0.010" | 5 | $59.20 | Add to Cart | ||
| 2803F2866 | Shim 0.197" Idler Bearing Kit 2947 | 5 | — | Call for availability | ||
| 2803Q4255 | Shim 0.003" (idler) | 5 | $55.10 | Add to Cart | ||
| 2803P4254 | Shim 0.005" (idler) | 5 | Housing bearing cups | $58.50 | Add to Cart | |
| 2803N4252 | Shim 0.010" (idler) | 5 | $56.40 | Add to Cart | ||
| US8887259355 | Meritorpartsonline.com | 7 | — | Call for availability | ||
| CANADA8003873889 | — | Call for availability |
Seal and Bearing Kit 2946
| Item | Part No. | Description | Qty | Notes | Price | |
|---|---|---|---|---|---|---|
| A3226D1512 | Bearing Cage Assembly | 1 | $297.28 | Add to Cart | ||
| 40X1233 | Lock Nut | 4 | M45 1 .5 thd.; x | $17.72 | Add to Cart | |
| 1229N1730 | Flat Washer | 4 | 1 .79" ID 3.00" OD 0.19" wide; x x | $52.70 | Add to Cart | |
| R945007 | Seal Assembly (front & Rear Output) | 2 | 3.25" ID 4.25" OD 0.86" long; x x | $108.48 | Add to Cart | |
| A11205X2728 | Seal Assembly (input) | 1 | 3.25" ID 4.25" OD 0.58" long; x x | $104.91 | Add to Cart | |
| 40X1341 | Lock Nut | 1 | 2.25"-12 thd. | $149.13 | Add to Cart | |
| 1229E4113 | Washer | 1 | 2.28" ID 3.25" OD 0.32" wide; x x | $360.25 | Add to Cart | |
| A1228K2273 | Needle Bearing | 2 | $56.26 | Add to Cart | ||
| HM813810 | Bearing Cup | 3 | 5.00" OD; cup | $46.33 | Add to Cart | |
| HM212011 | Bearing Cup | 3 | 4.8125" OD; cup | $21.22 | Add to Cart | |
| 1228J1804 | Bearing Cup | 2 | (1228-V-2362) | $48.90 | Add to Cart | |
| HM212049 | Bearing Cone | 3 | 2.625" ID cone | $37.35 | Add to Cart | |
| HM813843 | Bearing Cone | 3 | 2.4375" ID cone | $117.23 | Add to Cart | |
| A1228M1807 | Bearing Cone Kit 2598 | 2 | $97.59 | Add to Cart | ||
| 3261A1067 | Shift Cylinder | 1 | $24.14 | Add to Cart | ||
| 5X1326 | O-ring | 1 | 1 .459" ID 0.208" thick; x | $17.60 | Add to Cart | |
| 5X1290 | O-ring (inner) | 1 | 0.734" ID 0.139" thick; x | $4.42 | Add to Cart | |
| 2230Q1369 | Piston (outer) Meritorpartsonline.com | 1 | U.S. 888-725-9355; Canada 800-387-3889 | $188.24 | Add to Cart |
This is the complete factory parts breakdown for the Meritor MTC-4210XLEV Transfer Case — every part in the manual, matched to our live inventory. We stock 119 of the 139 parts above; click any part number to view it, or add it straight to your cart. Click a number on any diagram to jump to that part.
